Запчасти Case 1850K (1.211[23]) - TRANSMISSION - COMPONENTS Hydrostatic Transmission

1

581371

THRUST PLATE

1шт.

2

590537

GEAR

54T

1шт.

3

4951301

NUT

1шт.

4

4960759

FLANGE

1шт.

5

4962194

SPACER

1шт.

6

4985508

GEAR

54T

1шт.

7

11071376

SNAP RING,M90, Ext

(84.5 Free ID x 3 Thk)

1шт.

8

11071876

SNAP RING,M100, Ext

(94.5 Free ID x 3 Thk)

1шт.

9

14457281

O-RING,0.612" ID x 0.103" Width

(M15.54 ID x 2.62 Thk)

2шт.

10

14463881

O-RING,1.359" ID x 0.139" Width

2шт.

11

14465481

O-RING,3.234" ID x 3.512" OD x 0.139"

(M82.14 ID x 3.53 Thk)

1шт.

12

14496631

WASHER,10.5mm ID x 21mm OD x 2mm Thk

2шт.

13

15970731

BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd

2шт.

14

20943310

BALL BEARING,40mm ID x 90mm OD x 23mm W

40 x 90 x 23 mm

1шт.

15

76087581

BALL BEARING,50mm ID x 80mm OD x 16mm W

50 x 80 x 16 mm

2шт.

16

28996360

BALL BEARING,60mm ID x 110mm OD x 22mm W

60 x 110 x 22 mm

1шт.

17

40000110

SEAL

35 x 62 x 10 mm

1шт.

18

76027781

IDLE SHAFT

Assy

1шт.

19

79086720

SEAL,Split, 17mm ID x 19.8mm OD x 1.57mm Thk

In Alternative

2шт.

19

79051013

SEAL,20.168mm OD x 1.143mm Width

In Alternative

2шт.

20

79060757

PIN,19.8mm OD x 98mm L

1шт.

21

76027777

BUSHING,20.03mm ID x 26mm OD x 27mm L

1шт.
