Запчасти Case 1650M WT/LGP (10.414.AC[02]) - FAN ASSEMBLY (10) - ENGINE

Схема запчастей Case 1650M WT/LGP - (10.414.AC[02]) - FAN ASSEMBLY (10) - ENGINE
11
5
18
22
14
12
23
28
15
19
27
24
15
3
3
3
3
28
23
20
10
13
3
9
21
29
29
16
7
24
home
1
12
3
30
25
17
19
8
21
4
29
13
6
2
27
29
26

Артикул

Название

Примечание

Количество

1

425-1310

SLOTTED NUT,5/8"-18, G5

1шт.

2

733-3232

COTTER PIN,M3.2 x 32

1шт.

3

43139

BOLT,M10 x 1.5 x 25mm, Cl 8.8

6шт.

4

513309

HOSE CLAMP,1-1/16” - 2”, Worm Gear

1шт.

5

9824642

BOLT,M12 x 1.75 x 42.68mm, Cl 10.9

2шт.

6

9840535

HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB

1шт.

7

9993143

HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB

1шт.

8

47530507

RIGID TUBE

Fan Pump Supply

1шт.

9

47530509

HOSE ASSY.,38.1mm ID x 1730mm L, SAE 100R4

Fan Supply

1шт.

10

47530510

ANGLE

Plate, Tube Support

1шт.

11

47601008

HOSE,19.05mm ID x 690mm L, SAE 100R16

Hydraulic Pump to Valve

1шт.

12

9991976

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

2шт.

13

47621918

CLAMP,17.5mm, Coat, 11.9mm Bolt Hole, P Type

Closed

2шт.

14

84180945

COLLAR CLAMP,1.87" - 2.18"

T - Bolt

2шт.

15

84256799

90 ELBOW

1шт.

16

84375593

SWITCH

Engine Fan Reverse Rocker

1шт.

17

84398131

HYDRAULIC PUMP,33 CC

Fan 29cc

1шт.

17

84398131R

REMAN-HYD PUMP

Fan 29cc

1шт.

17

84398131C

CORE-HYDRAULIC PUMP

Return Number

1шт.

18

84561111

HYDRAULIC HOSE,25.4mm ID x 2373mm L, SAE 100R16

Fan To Filter

1шт.

19

9824050

O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro

2шт.

20

84592530

HYDRAULIC HOSE,9.53mm ID x 3060mm L, SAE 100R1

Fan Drain

1шт.

21

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

2шт.

22

86625255

WASHER,13.3mm ID x 24.5mm OD x 3mm Thk

2шт.

23

86634189

CLAMP,50.8mm, Coat, 13.5mm Bolt Hole, P Type

2шт.

24

87353455

CLAMP,34.9mm, Coat, 13.5mm Bolt Hole, P Type

2шт.

25

87373112

WASHER,20mm ID x 36mm OD x 7.5mm Thk

Gear Mounting

1шт.

26

87389871

GEAR

Accesory Drive

1шт.

27

87417721

THREADED INSERT,M10 x 1.5-6H x 29 L

2шт.

28

87655046

SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk

2шт.

29

87687101

WASHER,10.65mm ID x 31mm OD x 3.3mm Thk

4шт.

30

A77441

GASKET

Hydraulic Pump

1шт.

Выбрано товаров: 32
