Запчасти Case 1450 (102) - FRONT ELECTRICAL WIRING, INSTRUMENT PANEL TO ALTERNATOR, ENG & HEADLIGHTS (04) - ELECTRICAL SYSTEMS

1

R29351

HARNESS

- front, before tractor sn 8380101

1шт.

1

R40134

LOOM

HARNESS - front, tractor sn 8380101 and after

1шт.

2

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

1шт.

3

92-6

LOCK WASHER,3/8"

1шт.

4

D47783

CLAMP

- harness

1шт.

5

13-512

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

1шт.

6

92-5

LOCK WASHER,5/16"

1шт.

7

49852

PTO SHAFT

- harness

1шт.

8

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

1шт.

9

92-6

LOCK WASHER,3/8"

1шт.

10

49851

SHIELD

- harness

1шт.

11

13-660

BOLT,Hex, 3/8" - 16 x 3-3/4", Gr 5

HHCS - 3/8" - 16 NC x 3-3/4", R28517 strap

1шт.

11

13-644

BOLT,Hex, 3/8" - 16 x 2-3/4", Gr 5

HHCS - 3/8" - 16 NC x 2-3/4", R33392 strap

1шт.

11

13-640

BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5

HHCS - 3/8" - 16 NC x 2-1/2", R40122 strap

1шт.

12

92-6

LOCK WASHER,3/8"

1шт.

13

95-6

WASHER,3/8"

- flat, 3/8"

1шт.

15

R33392

STRAP

- alternator adjusting, before tractor sn 8380101

1шт.

15a

R40122

STRAP

- offset, tractor sn 8380101 and after

1шт.

16

13-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5, Full Thd

R27267 and R34730 alternator Hex, 1/2"-13 x 1 1/4", G5, Full Thd

1шт.

16

13-516

BOLT,Hex, 5/16" - 18 x 1", Gr 5

R36588 alternator Hex, 5/16"-18 x 1", G5, Full Thd

1шт.

17

92-8

LOCK WASHER,1/2"

1шт.

17

92-5

LOCK WASHER,5/16"

1шт.

18

D26752

WASHER

- special, 1/2"

1шт.

18

195-21

WASHER,5/16"

- flat, 5/16"

1шт.

19

R27267

ALTERNATOR - Prestolite no. ANB-7002, parts list Figures 76 and 78

1шт.

19

R34730

ALTERNATOR - Prestolite no. ANB-7003, parts list Figures 76 and 78

1шт.

19

R36588

ALTERNATOR

- Motorola No 70 D44966E01, parts list Figures 80 and 82

1шт.

20

13-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5, Full Thd

R27267 and R34730 alternator Hex, 1/2"-13 x 1 1/2", G5, Full Thd

1шт.

20

13-648

BOLT,Hex, 3/8" - 16 x 3", Gr 5

HHCS - 3/8" - 16 NC x 3", R36588 alternator

1шт.

21

92-8

LOCK WASHER,1/2"

1шт.

21

92-6

LOCK WASHER,3/8"

1шт.

22

95-8

WASHER,1/2"

flat 1/2"

1шт.

22a

25-106

NUT,3/8"-16, G5

- hex, 3/8" - 16 NC

1шт.

23

13-616

BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd

Models without winch Hex, 3/8"-16 x 1", G5, Full Thd

2шт.

23

13-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5, Full Thd

Models with winch Hex, 3/8"-16 x 1 1/4", G5, Full Thd

2шт.

24

92-6

LOCK WASHER,3/8"

2шт.

25

R27258

BRACKET

- before tractor sn 8380101

1шт.

25a

A38492

BRACKET

- tractor sn 8380101 and after

1шт.

25a

R33006

SPACER

- alternator, models with winch

1шт.

26

13-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5, Full Thd

1шт.

27

92-6

LOCK WASHER,3/8"

1шт.

28

80049853

YOKE

- harness

1шт.

29

D41077

STRAP

- harness, 10"

2шт.

30

D41075

STUD

- strap

2шт.

31

R29239

HARNESS

- head lights

1шт.

32

A11768

ELECTRICAL WIRE

WIRE - ground

2шт.

33

129-17

NUT,Hex, #10 - 24

NUT - hex, no. 10 - 24 NC

6шт.

34

192-18

LOCK WASHER,Helical Spring, #10, 0.196" ID, CST, ZND

WASHER, LOCK, #10

6шт.

35

R31131

LAMP

LIGHT - head, parts list Figure 104

2шт.

36

L18331

CABLE TIE,375.9mm L, Nylon

STRAP - plastic

1шт.

37

A41361

PULLEY

- R36588 alternator

1шт.
