Запчасти Case 1450 (330) - D77640 RELIEF VALVE (08) - HYDRAULICS

Схема запчастей Case 1450 - (330) - D77640 RELIEF VALVE (08) - HYDRAULICS

Артикул

Название

Примечание

Количество

D77640

VALVE

- relief, Includes: Ref. 1 - 15

1шт.

1

129-526

CROWN NUT,Low, 3/8" - 24

- domed, 3/8" - 24 NF

1шт.

2

86585245

SPECIAL NUT,JAM, 5/8" - 18

- hex lock, 3/8" - 24 NF

1шт.

3

D78362

SCREW

- adjusting

1шт.

4

D78363

BODY

- upper

1шт.

5

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

6

D78364

PISTON ASSY.

PISTON

1шт.

7

D26265

O-RING,1.78mm Thk x 14mm ID, 70 Duro

1шт.

8

D66203

SPRING

1шт.

9

D66202

SPOOL

POPPET

1шт.

10

S84196

BACK-UP RING,9/16" ID x 3/4" OD x 0.052"

- backup

1шт.

11

A30097

O-RING,0.549" ID x 0.755" OD x 0.103"

1шт.

12

D66200

BODY

- lower

1шт.

13

218-5009

O-RING,0.116" Thk x 1.048" ID, -914, Cl 6, 90 Duro

1шт.

14

A62239

O-RING,0.07" Thk x 0.926" ID, -21, Cl 5, 75 Duro

1шт.

15

R31052

O-RING,15/16" ID x 1-1/16" OD x 3/64"

RING - backup

1шт.

Выбрано товаров: 16
