Запчасти Case 1150C (360) - MAIN FRAME, PIVOT SHAFT, & PULL HOOK DPZER & DRAWBAR MODELS (09) - CHASSIS/ATTACHMENTS

1

R31422

WEIGHT

COUNTERWEIGHT - rear, 2000 lbs (907 kg), loader models

1шт.

2

13-1672

BOLT,Hex, 1" - 8 x 4-1/2", Gr 5

6шт.

3

D36505

WASHER,26.99mm ID x 47.63mm OD x 2.38mm Thk

- hardened

6шт.

4

R31423

WEIGHT

COUNTERWEIGHT - rear, 1000 lbs (454 kg), loader models with clam bucket

1шт.

5

15-16256

BOLT

- hex head, 1" - 8 NC x 16"

2шт.

6

K5386

WASHER

- special

2шт.

7

R29775

BUSHING

SPACER - counterweight

2шт.

8

R29774

BLOCK

- tapped

2шт.

9

R41701

WEIGHT

COUNTERWEIGHT - front, 1200 lbs (544 kg), dozer models

1шт.

10

13-1672

BOLT,Hex, 1" - 8 x 4-1/2", Gr 5

2шт.

11

195-53

WASHER,1" x 2" x .134"

- flat, 1"

2шт.

12

25-1016

NUT,1"-8, G5

2шт.

13

13-1088

BOLT,Hex, 5/8" - 11 x 5-1/2", Gr 5

- hex head, 5/8" - 11 NC x 5-1/2"

4шт.

14

92-10

LOCK WASHER,5/8"

WASHER, LOCK, 5/8"

4шт.

15

195-41

WASHER,5/8"

4шт.

16

71671

PLATE ASSY.

HOOK - pull, if used

1шт.

17

13-1256

BOLT,Hex, 3/4" - 10 x 3-1/2", Gr 5

Used without pull hook Hex, 3/4"-10 x 3 1/2", G5

4шт.

18

13-1264

BOLT,Hex, 3/4" - 10 x 4", Gr 5

Used with pull hook Hex, 3/4"-10 x 4", G5

4шт.

19

195-45

WASHER,3/4"

Used without pull hook 3/4"

4шт.

20

R26802

SPACER

- front counterweight

2шт.

21

R32699

BALANCER

COUNTERWEIGHT - rear, 500 lbs (227 kg), no longer available, order R46930 counterweight, ref. 21A

1шт.

21a

R46930

BALANCER

COUNTERWEIGHT - rear, 500 lbs (227 kg)

1шт.

22

13-1680

CAPSCREW,Hex, 1" - 8 x 5", Gr 5

BOLT, Hex, 1"-8 x 5", G5

2шт.

23

D36505

WASHER,26.99mm ID x 47.63mm OD x 2.38mm Thk

- hardened

2шт.

24

25-1016

NUT,1"-8, G5

2шт.
