(1150) - CASE TORQUE CONVERTER CRAWLER TRACTOR (S/N 7110300 & AFTER) (7/69-12/74)
/
(07) - HYDRAULIC SYSTEM
/

(224) - LOADER CONTROL VALVES, USED BEFORE TRACTOR SN. 7300094, D41534 LOADER CONTROL VALVE (3 SPOOL)

Запчасти Case 1150 (224) - LOADER CONTROL VALVES, USED BEFORE TRACTOR SN. 7300094, D41534 LOADER CONTROL VALVE (3 SPOOL) (07) - HYDRAULIC SYSTEM

Схема запчастей Case 1150 - (224) - LOADER CONTROL VALVES, USED BEFORE TRACTOR SN. 7300094, D41534 LOADER CONTROL VALVE (3 SPOOL) (07) - HYDRAULIC SYSTEM
9
6
5
11
14
8
7
10
15
2
13
3
12
1
4

№

Артикул

Название

Примечание

Количество

D41534

VALVE - loader control, 3 spool (When stock is exhausted, Use D49928 valve (Parts list figure 226), Includes: Ref. 1 - 7

1шт.

1

D32112

NO LONGER SERVICED

INLET SECTION - loader control valve (Parts list figure 230)

1шт.

2

D38365

KNIFE SECTION

LIFT SECTION - loader control valve (Parts list figure 232)

1шт.

3

D48841

TILT SECTION - loader control valve (Parts list figure 238) When stock is exhausted, use D49980 section

1шт.

3

D49980

X

TILT SECTION - lower control valve (Parts list figure 240)

1шт.

4

D41533

VALVE

BUCKET CLAM OR RIPPER SECTION - loader control valve (Parts list figure 236)

1шт.

5

D38360

VALVE

OUTLET SECTION - loader control valve (Parts list figure 230)

1шт.

6

R20429

STUD

ASSEMBLY - valve

4шт.

7

195-33

WASHER,1/2"

- plain () 1/2"

4шт.

D41535

LOCK VALVE

VALVE - loader control, 4 spool (When stock is exhausted, use D49929 valve - parts list figure 226), Includes: Ref. 8 - 15

1шт.

8

D32112

NO LONGER SERVICED

INLET SECTION - loader control valve (Parts list figure 230), D41535 (4 spool)

1шт.

9

D38365

KNIFE SECTION

LIFT SECTION - loader control valve (Parts list figure 232), D41535 (4 spool)

1шт.

10

D48841

TILT SECTION - loader control valve (Parts list figure 238) When stock is exhausted, use D49980 section, D41535 (4 spool)

1шт.

10

D49980

X

TILT SECTION - loader control valve (Parts list figure 240), D41535 (4 spool)

1шт.

11

D32123

KNIFE SECTION

BUCKET CLAM SECTION - loader control valve (Parts list figure 234), D41535 (4 spool)

1шт.

12

D41533

VALVE

RIPPER SECTION - loader control valve (Parts list figure 236), D41535 (4 spool)

1шт.

13

D38360

VALVE

OUTLET SECTION - loader control valve (Parts list figure 230), D41535 (4 spool)

1шт.

14

D36476

STUD

ASSEMBLY - valve, D41535 loader control (4 spool)

4шт.

15

195-33

WASHER,1/2"

- plain (), D41535 loader control valve (4 spool) 1/2"

4шт.

Выбрано товаров: 19
