(01-001AB-00[01]) - QUICK REFERENCE TO FREQUENTLY ORDERED PARTS

Запчасти Case SV228 (01-001AB-00[01]) - QUICK REFERENCE TO FREQUENTLY ORDERED PARTS FAST MOVING PARTS

Схема запчастей Case SV228 - (01-001AB-00[01]) - QUICK REFERENCE TO FREQUENTLY ORDERED PARTS FAST MOVING PARTS
25
1
26
10
10-001-01
10-004-01
02-006-01
18
24
17
1
02-001-01
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

10

ND090777

AIR FILTER

1шт.

Air Filter

1шт.

11

ND090778

AIR FILTER

1шт.

Air Filter

1шт.

17

ND065484

ELEMENT

1шт.

REF

INSTRUCTION

O-Ring Used With Filter Element Is Part Number 192200280704

1шт.

Filter - Travel

1шт.

18

ND067790

FILTER STRAINER

1шт.

Oil Tank

1шт.

24

ND090931

FUEL FILTER

1шт.

Engine

1шт.

25

ND090932

FUEL FILTER

1шт.

Engine

1шт.

26

ND090933

ELEMENT

2шт.

Engine

1шт.
