Запчасти Case SV212 (55.408.02) - DIFFERENTIAL LOCK (HT, ANT-SLIP) - BSN DDD003017 (55) - ELECTRICAL SYSTEMS

REF

INSTRUCTION

DIFFERENTIAL LOCK (ND109554) (GROUP 420)

1шт.

1

ND031355

PLATE

1шт.

3

ND109542

WIRE HARNESS

Until P.I.N. DDD001142

1шт.

3

ND136819

HARNESS

P.I.N. DDD001143 And After

1шт.

6

ND109932

ECU

1шт.

7

ND090938

SENSOR

1шт.

8

ND117222

SOCKET/RECEPTACLE

1шт.

9

ND065398

INDICATOR LIGHT

1шт.

10

ND108147

IDENTITY PLATE

1шт.

11

ND065354

LENS

1шт.

12

ND065422

SWITCH

1шт.

13

ND065142

RELAY

1шт.

14

ND065143

HOLDER

1шт.

18

ND024100

BOLT

2шт.

19

ND024110

BOLT

4шт.

20

ND093424

BOLT

1шт.

21

ND021302

BOLT

2шт.

24

ND107946

NUT

2шт.

25

ND107948

LOCK NUT

1шт.

26

ND027301

NUT

2шт.

29

ND029306

WASHER

4шт.

30

ND029311

WASHER

2шт.

33

ND029249

WASHER

2шт.
