Запчасти Case SV216 (04-007-00[01]) - ELECTRICAL - CIRCUIT - DIFFERENTIAL LOCK (GROUP 42O) (ND109554) (04) - ELECTRICAL SYSTEMS

ELECTRICAL INSTALLATION (ND109554) (Group 420)

1шт.

1

ND031355

PLATE

1шт.

3

ND109542

WIRE HARNESS

HARNESS

1шт.

6

ND109932

ECU

CONTROL UNIT

1шт.

7

ND090938

SENSOR

SENDING UNIT

1шт.

8

ND117222

SOCKET/RECEPTACLE

SOCKET

1шт.

9

ND065398

INDICATOR LIGHT

PILOT LAMP

1шт.

10

ND108147

IDENTITY PLATE

RATING PLATE

1шт.

11

ND065354

LENS

RATING PLATE

1шт.

12

ND065422

SWITCH

HEADLIGHT

1шт.

13

ND065142

RELAY

1шт.

14

ND065143

HOLDER

BASE

1шт.

18

ND024100

BOLT

M3 x 8 BOLT

2шт.

19

ND024110

BOLT

M4 x 12 BOLT

4шт.

20

ND093424

BOLT

1шт.

21

ND021302

BOLT

BOLT

2шт.

24

ND107946

NUT

2шт.

25

ND107948

LOCK NUT

LOCKING NUT

1шт.

26

ND027301

NUT

2шт.

29

ND029306

WASHER

ID 4,1 SPRING

4шт.

30

ND029311

WASHER

ID -10,2 SPRING

2шт.

33

ND029249

WASHER

ID 8,4

2шт.
