Запчасти Case PT240 (44.100.06[02]) - WHEEL SCRAPER-OPTIONAL-BREAKDOWN - DDDPT240NANTN2000 (44) - WHEELS
![Схема запчастей Case PT240 - (44.100.06[02]) - WHEEL SCRAPER-OPTIONAL-BREAKDOWN - DDDPT240NANTN2000 (44) - WHEELS](https://partsell.ru/storage/images/casece/1047658.png)
44.100.01 02
15
6
12
5
17
1
6
11
9
15
7
18
9
13
8
13
6
3
16
14
16
11
2
4
17
10
15
10
15
19
6
1
ND138790
BRACKET
1шт.
2
ND026472
NUT
1шт.
3
ND127356
BRACKET
1шт.
4
ND127355
BRACKET
1шт.
5
ND127359
LOCKING HANDLE
1шт.
6
ND029291
WASHER
8шт.
7
ND127341
HOLDER
1шт.
8
ND121644
SPRING
1шт.
9
ND110781
STRAP
2шт.
10
ND110784
BLADE
2шт.
11
ND116364
BRUSH
2шт.
12
ND035940
SPRING WASHER
2шт.
13
ND029249
WASHER
8шт.
14
ND021331
BOLT,Hex, M16 x 40mm
1шт.
15
ND021848
NUT
12шт.
16
ND021296
BOLT
4шт.
17
ND025745
CARRIAGE BOLT
8шт.
18
ND021295
BOLT
2шт.
19
ND021851
NUT
1шт.
