Запчасти Case DV210 (44.511.01) - FRONT DRUM MOUNTING (GROUP 1-ND125932) (44) - WHEELS

1

ND125933

DRUM

DRUM

1шт.

2

ND125935

DAMPER

PLATE, DAMPER

1шт.

3

ND125958

BRACKET

BRACKET

1шт.

4

ND125959

BRACKET

BRACKET

1шт.

5

ND125954

CROSSMEMBER

CROSSMEMBER

1шт.

6

ND090009

PAD

DAMPER

10шт.

7

ND068978

ROLLER BEARING

2шт.

9

ND125936

BRACKET

BRACKET

2шт.

10

ND126002

FLANGE

FLANGE

1шт.

11

ND126003

FLANGE

FLANGE

1шт.

12

ND148386

BRACKET

1шт.

13

ND148387

BRACKET

1шт.

16

ND128385

BOLT

BOLT

1шт.

17

ND125937

SHAFT

1шт.

18

ND125938

ECCENTRIC

1шт.

19

ND125939

ECCENTRIC

1шт.

20

ND125940

ECCENTRIC

1шт.

21

ND125941

ECCENTRIC

1шт.

22

ND125934

CARRIER

CARRIER

1шт.

23

ND129491

MOUNTING PLATE

PLATE, MOUNTING

1шт.

24

ND119427

RING

2шт.

25

ND123030

TRANSMISSION

TRANSMISSION

1шт.

26

ND123031

SPLINED COUPLING

1шт.

33

ND033848

KEY

1шт.

36

ND126079

HOSE

1шт.

37

ND069527

HYD CONNECTOR

Elbow

1шт.

38

ND069526

HYD CONNECTOR

1шт.

39

ND062402

PLUG

1шт.

40

ND130108

BUSHING

2шт.

42

ND068872

ROLLER BEARING

BEARING

1шт.

43

ND068989

RING

2шт.

44

ND079944

RING

RING

1шт.

45

ND069851

LOCKING RING

RING, LOCKING

2шт.

47

ND069911

LOCKING RING

2шт.

48

ND033820

KEY

1шт.

49

ND021301

BOLT

4шт.

51

ND021303

BOLT

6шт.

52

ND021310

BOLT

58шт.

53

ND021309

BOLT,M12 x 25

24шт.

54

ND021313

BOLT

16шт.

57

ND021331

BOLT,Hex, M16 x 40mm

8шт.

58

ND021333

BOLT

18шт.

59

ND021334

BOLT

BOLT

18шт.

60

ND021344

BOLT

8шт.

61

ND035827

WASHER

8шт.

62

ND029267

WASHER

18шт.

63

ND021354

BOLT

18шт.

65

ND035941

WASHER

10шт.

66

ND035943

WASHER

36шт.

67

ND035944

WASHER

Spring

8шт.

68

ND035946

SPRING WASHER

18шт.

72

ND034086

NUT

80шт.

73

ND021851

NUT

18шт.

78

ND065651

PLUG

Magnetic

2шт.

79

ND107208

BLEEDER

Valve

1шт.

85

ND079915

RING

RING

1шт.

86

ND079851

RING

RING

1шт.

88

ND079945

RING

RING

1шт.

89

ND079047

OIL SEAL

SEAL, OIL

1шт.
