Запчасти Case F4HFE4135 B003 (10.400.AE) - COOLING SYSTEM LINE (10) - ENGINE

1

2852212

FLANGE BOLT,Hex, M8 x 1.25 x 25mm

3шт.

2

2854072

SEALING RING,Square, 5.16mm Thk x 50.17mm ID

2шт.

3

47589691

SUPPORT

ASSY, Incl 4, 5

1шт.

4

NSS

NOT SOLD SEPARAT

Support, incl in 3

1шт.

5

98405182

DOWEL

2шт.

6

4895393

O-RING,2.2mm Thk x 15.3mm ID

1шт.

7

4895080

HEX SOCKET PLUG,M22 x 1.5

ASSY, Incl 8, 9

1шт.

8

NSS

NOT SOLD SEPARAT

Plug, Incl in 7

1шт.

9

4895082

O-RING,19.3mm ID x 2.2mm Width

1шт.

10

4892762

PLUG,1/4 - 18" OD x 0.46" L

1шт.

11

4895078

PIPE PLUG,1/2"-14

2шт.

12

2855462

BRACKET

1шт.

13

4895623

HEX SOCKET PLUG,M16 x 1.5

ASSY, Incl 14, 15

1шт.

14

NSS

NOT SOLD SEPARAT

Plug, Incl in 13

1шт.

15

4895625

O-RING,13.3mm ID x 2.2mm Width

1шт.

16

4893036

PIPE PLUG,3/4"-14 NPTF

2шт.

17

4895392

HEX SOCKET PLUG,M18 x 1.5

ASSY, Incl 6, 18

1шт.

18

4895394

HEX SOCKET PLUG,M18 x 1.5

1шт.

19

47565455

FITTING,M12 x 1.5 x 20mm D

1шт.

20

4895227

GUIDE RING,11.15mm OD, 8.5mm ID, 9mm L

2шт.
