1
2852286
BOLT,Flng, M10 x 1.5 x 130mm
2шт.
2
2854072
SEALING RING,Square, 5.16mm Thk x 50.17mm ID
2шт.
3
2854938
FITTING
ASSY, Incl 2, 4, 5, Alternative
1шт.
3
4892347
SUPPORT
ASSY, Incl 2, 4, 5, Alternative
1шт.
4
4895576
DOWEL
2шт.
5
NSS
NOT SOLD SEPARAT
Support, Incl in 3
1шт.
6
4895392
HEX SOCKET PLUG,M18 x 1.5
ASSY, Incl 7, 8
2шт.
7
4895393
O-RING,2.2mm Thk x 15.3mm ID
2шт.
8
NSS
NOT SOLD SEPARAT
Plug, Incl in 6
1шт.
9
4895625
O-RING,13.3mm ID x 2.2mm Width
1шт.
10
NSS
NOT SOLD SEPARAT
Plug, Incl in 11
1шт.
11
4895623
HEX SOCKET PLUG,M16 x 1.5
ASSY, Incl 9, 10
1шт.
12
4893036
PIPE PLUG,3/4"-14 NPTF
2шт.
13
NSS
NOT SOLD SEPARAT
Plug, Incl in 14
1шт.
14
4895080
HEX SOCKET PLUG,M22 x 1.5
ASSY, Incl 13, 15
1шт.
15
2854072
SEALING RING,Square, 5.16mm Thk x 50.17mm ID
1шт.
16
4895078
PIPE PLUG,1/2"-14
3шт.
17
4895292
FLANGE BOLT,Hex, M10 x 1.5 x 70mm
1шт.
18
2854491
PLUG,Taper Pipe, Hex, 1/4" - 18 x 14.224mm
1шт.
