1
47528926
PIPE
ASSY, Incl 2, 3
1шт.
2
4894095
O-RING,2.5mm Thk x 8mm ID, 60 Duro
2шт.
3
2854572
90 ELBOW
Pipe, Incl in 1
1шт.
4
47528927
PIPE
ASSY, Incl 5, 6
1шт.
5
4894095
O-RING,2.5mm Thk x 8mm ID, 60 Duro
4шт.
6
2854572
90 ELBOW
Pipe, Incl in 4
1шт.
7
47528929
PIPE
ASSY, Incl 5, 9
1шт.
8
4897277
SCREW
2шт.
9
2854572
90 ELBOW
Pipe, Incl in 7
1шт.
10
47528951
BRACKET
2шт.
11
47528950
BRACKET
3шт.
12
47528949
BRACKET
1шт.
13
47700378
PIPE
ECM to pump tube, ASSY, Incl 14, 15
1шт.
14
4894095
O-RING,2.5mm Thk x 8mm ID, 60 Duro
1шт.
14
4890929
O-RING,3mm Thk x 11mm ID
2шт.
15
NSS
NOT SOLD SEPARAT
Pipe, Incl in 13
1шт.
16
86625036
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
17
9804260
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
1шт.
18
2856006
SPACER
1шт.
19
10441390
COLLAR,12mm, Coat, 7mm Bolt Hole, P Type
1шт.
20
9804255
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
1шт.
