1
47529779
PIPE
ASSY, Incl 2, 3
1шт.
1
5801584068
INJECTION PIPE,PIPE ASSY INJ PUMP TO FI
1шт.
2
4894095
O-RING,2.5mm Thk x 8mm ID, 60 Duro
2шт.
3
2854572
90 ELBOW
Pipe, Incl in 1
1шт.
4
47530101
PIPE
ASSY, Incl 5, 6
1шт.
4
5801634202
INJECTION PIPE,PIPE ASSY INLET TO INJ P
1шт.
5
4894095
O-RING,2.5mm Thk x 8mm ID, 60 Duro
4шт.
6
2854572
90 ELBOW
Pipe, Incl in 4
1шт.
7
47530099
PIPE
ASSY, Incl 5, 9
1шт.
7
5801602985
FUEL TUBE,PIPE ASSY RETURN TO TANK
1шт.
8
4897277
SCREW
2шт.
9
2854572
90 ELBOW
Pipe, Incl in 7
1шт.
10
47528951
BRACKET
2шт.
10
5801640019
HOSE CLIP
2шт.
10
5801612942
CLIP,CLIP FUEL PIPE
2шт.
11
47529785
CLIP
1шт.
12
47528949
BRACKET
1шт.
13
47542097
PIPE
ASSY, ECM to Pump Tube, Incl 14, 15
1шт.
13
5801582683
TUBE,TUBE ASSY ECM TO PUMP
1шт.
14
4890929
O-RING,3mm Thk x 11mm ID
2шт.
15
NSS
NOT SOLD SEPARAT
Pipe, Incl in 13
1шт.
16
86625036
CLAMP,12.7mm, Coat, 8.7mm Bolt Hole, P Type
1шт.
16
18179598
CLAMP
1шт.
17
9804260
BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8
1шт.
17
16673834
SCREW,M8 x 30mm
1шт.
18
2856006
SPACER
1шт.
18
17816314
BAR
1шт.
19
10441390
COLLAR,12mm, Coat, 7mm Bolt Hole, P Type
1шт.
20
9804255
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
1шт.
