Запчасти Case F4DFE613N B006 (10.103.AK) - FLYWHEEL & HOUSING (10) - ENGINE

1

504170041

HOUSING

1шт.

2

5801483583

OIL SEAL

1шт.

3

4894532

DOWEL,M18 x 10 L

2шт.

4

4895392

HEX SOCKET PLUG,M18 x 1.5

ASSY, Incl 11, 12

1шт.

5

4899385

FLANGE BOLT,Hex, M16 x 1.5 x 80mm, Cl 8.8

1шт.

6

504110650

ASSY, Incl 7, 13

COVER

1шт.

7

504108486

O-RING

1шт.

8

4895586

SCREW,Hex, Flg Hd, M8 x 16

2шт.

9

4891250

BOLT,Flng, M12 x 1.75 x 78mm, Cl 10.9

15шт.

10

4899145

BOLT,Flng, M12 x 1.75 x 100mm

2шт.

11

NSS

NOT SOLD SEPARAT

Plug, Incl in 4

1шт.

12

4895393

O-RING,2.2mm Thk x 15.3mm ID

1шт.

13

NSS

NOT SOLD SEPARAT

Cover, Incl in 6

1шт.
