Запчасти Case F3DFA613A E001 (10.101.03) - ENGINE BREATHERS (5801423698) (10) - ENGINE

1

504387086

BREATHER

ASSY Contains Ref.2, 3

1шт.

2

NSS

NOT SOLD SEPARAT

1шт.

3

504387088

SEAL

1шт.

4

5801400082

COVER

1шт.

5

5801400083

GASKET

1шт.

6

16585925

SCREW,Hex, M6 x 25mm, Cl 8.8

M6 x 25

27шт.

7

5801470547

ELEMENT

Breather

1шт.

8

18137825

BOLT,Hex, M6 x 16mm

M6 x 16

3шт.
