Запчасти Case F3AE0684G B001 (0.31.5/A[01]) - HEAT EXCHANGER AND PARTS (500386468)

1

504015758

HEAT EXCHANGER

1шт.

2

99434989

HEAT EXCHANGER

1шт.

3

14459081

O-RING,1.737" ID x 0.103" Width

2шт.

5

2855301

SCREW,Hex, M8 x 1.25 x 50mm

M8 x 50 MM

2шт.

6

99489014

SEALING WASHER

4шт.

7

99433799

PLUG

M32 x 1,5

1шт.

8

99433798

SPACER

1шт.

9

98498322

THERMOSTAT

1шт.

10

98494952

GASKET,35mm ID x 1.5mm Thk

1шт.

11

99469897

SENDER UNIT

1шт.

12

2852141

SENDER UNIT

Oil Temperature

1шт.

Version : BORLETTI

1шт.

12

2852142

SENDER UNIT

Oil Temperature

1шт.

Version : SIPEA

1шт.

13

4741616

BANJO BOLT

1шт.

14

500351609

SENDER UNIT

OIL PRESSURE

1шт.

15

504013552

SUPPORT

INCL.REF. 16

1шт.

16

500302241

HYDRAULIC VALVE

1шт.

17

504013562

GASKET

1шт.

18

2852267

FLANGE BOLT,Hex, M8 x 1.25 x 90mm

8шт.

19

10300714

PLUG,M16 x 1.5 x 14

3шт.

20

99489019

SEALING WASHER

DIA. MM 16 x 24 MM THK. 1,5

4шт.

21

16993711

PLUG,M35 x 1.5

M35 x 1.5

3шт.

22

99469380

GASKET,33mm ID x 45mm OD x 2.8mm Thk

D=33 mm

3шт.

23

10278301

PLUG,M28 x 1.5 x 11, Brass

3шт.

24

99432291

GASKET,28mm ID

D=28 mm

3шт.

25

98497873

GASKET

1шт.

26

2852295

SCREW,Hex, M8 x 1.25 x 40mm

M8 x 1,25 x 40 MM

14шт.

26

2852039

SCREW

2шт.
