(90.108.01[03]) - SAFETY DECALS - 4-SEATER

Запчасти Case IH SCOUT XL (90.108.01[03]) - SAFETY DECALS - 4-SEATER (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH SCOUT XL - (90.108.01[03]) - SAFETY DECALS - 4-SEATER (90) - PLATFORM, CAB, BODYWORK AND DECALS
3
6
2
5
7
9
4
8
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

CLC101547601

WARNING DECAL

Gasoling Explosion, Fire

1шт.

2

CLC102224001

DECAL

Rotating Parts

2шт.

3

CLC102231601

DECAL

Winch Cable Fracture

1шт.

4

CLC102458901

WARNING DECAL

Hot Surface

1шт.

5

CLC102459001

WARNING DECAL

Hot Manifold

1шт.

6

CLC102459101

WARNING DECAL

Frame Ground

1шт.

7

CLC102459201

WARNING DECAL

Diesel Explosion, Fire

1шт.

8

CLC102459501

WARNING DECAL

Rotating Parts and Hot Exhaust

1шт.

9

CLC102460201

WARNING DECAL

Rotating Parts

1шт.
