Запчасти Case IH SCOUT XL (33.202.05[01]) - HYDRAULIC BRAKE LINES AND CLIPS (33) - BRAKES & CONTROLS

Схема запчастей Case IH SCOUT XL - (33.202.05[01]) - HYDRAULIC BRAKE LINES AND CLIPS (33) - BRAKES & CONTROLS
7
3
3
9
1
10
5
3
3
8
7
10
2
4
3
5
3

Артикул

Название

Примечание

Количество

1

CLC101887601

LOCK NUT

1шт.

2

CLC102296140

BOLT

1шт.

3

CLC102296716

SCREW

5шт.

4

CLC102474301

BRACKET

Tee, Brake line

1шт.

5

CLC102475701

CLIP

Brake line

8шт.

6

CLC102541465

BOLT

1шт.

7

CLC102689001

BRACKET, SUPPORTING

2шт.

8

CLC102767001

BRAKE LINE

Rear, Inc. 9, Model Year 2011 And Prior

1шт.

8

CLC103842501

BRAKE LINE

Rear, Standard, Model Year 2012

1шт.

8

CLC103847101

BRAKE LINE

Rear, Stretch, Model Year 2012

1шт.

9

CLC102410603

CLAMP

1шт.

10

CLC103174301

BRAKE LINE

Front

1шт.

11

CLC8639

STRAP

1шт.

12

CLC103077501

ROTOR

Disc Rotor (Not Shown) Front and Rear for 2012

4шт.

Выбрано товаров: 14
