Запчасти Case IH SUPER C (195) - ATTACHMENTS, FAST-HITCH, SPECIAL Attachments

360185R91

ATTACHMENT, drawbar extension plate, provides standardized power take-off hitch, Composed of

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

360184R1

PLATE

1шт.

218197

NUT,3/4"-16, G5

2шт.

14-1240

BOLT,Hex, 3/4" - 16 x 2-1/2", Gr 5

SCREW

2шт.

103326

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

2шт.

1

360393R91

HOSE,0.25" ID x 29.25", SAE 100R1

HYDRAULIC HOSE - Control valve short, Will work for 361072R91 and 361953R91, Check & connections 0.25" ID x 29.25", SAE 100R1

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

2

360402R92

BLOCK

check valve, assembly, Composed of, connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

353953R1

SHAFT

ACTUATOR, check valve & connections

1шт.

360390R21

BLOCK, check valve & connections

1шт.

360391R1

PLUG, check valve & connections

1шт.

360392R1

PLUG, check valve & connections

1шт.

355967R1

O-RING,0.364" ID x 0.003" Width

RING, check valve & connections

1шт.

350668R1

VALVE SPRING

SPRING, check valve & connections

1шт.

354057R2

VALVE

check valve & connections

1шт.

13727D

GASKET

WASHER, check valve & connections

2шт.

3

360391R1

PLUG, check valve block, short, connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

4

13727D

GASKET

WASHER, plug, check valve block, connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

5

350668R1

VALVE SPRING

SPRING, check valve, connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

6

354057R2

VALVE

check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

7

360390R21

BLOCK, check valve, connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

8

353953R1

SHAFT

ACTUATOR, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

9

355967R1

O-RING,0.364" ID x 0.003" Width

RING, seal, check valve actuator,connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

10

360392R1

PLUG, check valve block, long, connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

11

454097

ELBOW

street, automotive pipe, stl., cd-pltd., 45 degrees, 1/4", optional with 360451R1, check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

11

360451R1

ELBOW, street, check valve to cylinder hose, optional with 454097, connections

1шт.

These parts are not included in battery ignition unit assembly.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

12

360394R91

HOSE ASSY.

HOSE, control valve, long, 1/4" I.D. x 31-3/4" long, check & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

13

444480

ELBOW

street, automotive pipe, brs., 90 degrees, 1/4", optional with 454109, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

13

454109

ELBOW

street, automotive pipe, stl., cd-pltd., 90 degrees, 1/4", optional with 444480, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

14

192053

NIPPLE, pipe, long, cd-pltd., 1/4 x 7/8", check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

15

454085

ELBOW, street, automotive pipe, stl., cd-pltd., 90 degrees, 1/4", optional with 444504, check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

15

444504

ELBOW, street, automotive pipe, brs., 90 degrees, 1/4", optional with 454085, check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

16

360383R1

CLAMP, auxiliary control valve hose, S/N 176523 up, check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

17

356809R1

CLAMP, auxiliary control valve hose, S/N 100001 to 176522, check & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

18

356835R1

BRACKET, auxiliary control valve hose, check & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

413-630

BOLT,Hex, 3/8" - 16 x 1-7/8", Gr 5

hex-hd., 3/8-16NC x 1-7/8", Check valve & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

19

356836R1

SPACER, auxiliary control valve hose bracket, check & connections

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

20

360393R91

HOSE,0.25" ID x 29.25", SAE 100R1

HYDRAULIC HOSE - Control valve short, Will work for 361072R91 and 361953R91, Check & connections 0.25" ID x 29.25", SAE 100R1

1шт.

These parts are not included in the fast hitch field attachments.

1шт.

Use only on tractors equipped with hoses and connections.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

21

9402805

ELBOW

control valve to check valve tube, connections

2шт.

Used only on tractors equipped with tubes and fittings.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

22

9402708

HYD CONNECTOR,9/16"-18, 37 Degree x 1/4"-18, NPTF

CONNECTOR, control valve to check valve tube, connections

2шт.

Used only on tractors equipped with tubes and fittings.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

23

361191R11

TUBE, control valve to check valve, long, w/two nuts, and two sleeves, connections

1шт.

Used only on tractors equipped with tubes and fittings.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

24

361190R11

TUBE, control valve to check valve short w/two nuts and two sleeves, connections

1шт.

Used only on tractors equipped with tubes and fittings.

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

359552R1

ARM, rockshaft, R.H., illustrated with rockshaft, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

15347D

NUT, rockshaft, check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

359554R1

PIN

rockshaft arm clevis, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

PO18500A

PIN

cotter, quick attachable, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

356831R1

BRACKET, auxiliary control valve lever, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

179801

BOLT,Hex, 1/4" - 20 x 1 1/2", Gr 5

Check valve & connections Hex, 1/4"-20 x 1 1/2", G5

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, , Check valve & connections 1/4"

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

358111R92

CABLE

switch to rear light, illustrated with lighting and starting system, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

61813D

CLIP

rear light cable, illustrated with lighting and starting system, check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

356803R1

GASKET

auxiliary control valve, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

356834R12

GUARD, hose auxiliary control valve, ilustrated with seat, seat support and tool box, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

413-412

BOLT,Hex, 1/4" - 20 x 3/4", Gr 5

SCREW, cap, hex-hd., 1/4-20NC x 3/4", check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

95-11028

WASHER,1/4"

plain, 9/32 I.D. x 5/8" O.D. x no. 16 ga., check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

356830R4

HANDLE, auxiliary control valve operating, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

52893H

CLEVIS PIN,3/8" x 1.781"

PIN, rod end, dld., 3/8 x 1-25/32", check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

103373

COTTER PIN,3/32" x 3/4"

Pin, Split (Cotter), , Check valve & connections 3/32" x 3/4"

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

360379R1

CHANNEL

LINK, connecting, auxiliary control valve, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

1161Y

PIN, rod end, dld., 5/16 x 23/32", check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

103373

COTTER PIN,3/32" x 3/4"

Pin, Split (Cotter), , Check valve & connections 3/32" x 3/4"

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

350667R1

O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro

RING, seal, manifold front flange, illustrated with auxiliary control valve, check & connections

4шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

357874R2

SCREW, cap, auxiliary control valve, illustrated with auxiliary control valve, check & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

360478R11

SUPPORT, rear light, illustrated with headlight and rear light supports, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

103026

NUT,3/8"-24, G5

Check valve & connections 3/8"-24, G5

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

181370

BOLT,Hex, 3/8" - 24 x 1 1/4", Gr 5

SCREW, cap, hex-hd., 3/8-24NF x 1-1/4", check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, , Check valve & connections 3/8"

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

359572R92

SUPPORT, seat and tool box, illustrated with seat, seat support and tool box, check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

356779R91

MANIFOLD

TUBES, manifold, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

cap, hex-hd., 3/8-16NC x 1-1/4", Check valve & connections

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, , Check valve & connections 3/8"

2шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

356788R92

VALVE, auxiliary control, assembly, illustrated with auxiliary control valve, check & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.

179846

LEVER

hex., 3/8-16NC x 1-7/8", Check valve & connections

1шт.

360434R94 ATTACHMENT, fast hitch (for tractors equipped with touch-control system) (S/N 100001 to 171175) ::1

1шт.

360933R93 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 171176 to 193534) ::1

1шт.

360934R94 ATTACHMENT, fast-hitch (for tractors equipped with touch-control system) (S/N 193535 up) ::1

1шт.
