Запчасти Case IH FARMALL HV (085) - ELECTRICAL SYSTEM, ELECTRIC LIGHTING, BOSCH NO-BATTERY GENERATOR, SPECIAL (06) - ELECTRICAL SYSTEMS

352835R91

BOSCH ("No-battery" generator) (Lighting attachment) (Machine attachment) (Two headlights and one rear light) (Complete attachments discontinued

1шт.

3281DAX

GENERATOR SADDLE WITH DOWEL PIN, 23603D

1шт.

181385

BOLT,Hex, 3/8" - 24 x 3", Gr 5

CAP SCREW, 3/8 x 3" N.F. hex head

1шт.

103026

NUT,3/8"-24, G5

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

6746DX

HUB

GENERATOR PULLEY FLANGE WITH SCREW, 102820 and nut, 114501

1шт.

6780D

CLAMP

LAMP CLAMP (Order 350920R1)

3шт.

9172D

GENERATOR PULLEY HUB

1шт.

9173DA

GENERATOR BRACKET

1шт.

179861

BOLT,Hex, 7/16" - 14 x 1 3/8", Gr 5

CAP SCREW, 7/16 x 1-3/8" N.C. hex head

2шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

2шт.

9231D

REAR LIGHT SUPPORT (Order 66836D) (S/N 501 to)

1шт.

179871

BOLT,Hex, 7/16" - 14 x 3 1/4", Gr 5

CAP SCRW, 7/16 x 3-1/4" N.C. hex head

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

3/8-16 x 1-1/4" N.C. hex

1шт.

280136

NUT,3/8"-16, G8

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

9231DA

REAR LIGHT SUPPORT (Optional with 353642R11)

1шт.

179874

BOLT,Hex, 7/16" - 14 x 4", Gr 5

1шт.

23603D

GENERATOR DOWEL PIN

1шт.

25830D

CLIP, cable harness and magneto switch (S/N 501 to)

1шт.

26080DB

GENERATOR STRAP

1шт.

181326

CAP SCREW, 1/4 x 2-3/4" N.F. hex head

1шт.

179822

BOLT,Hex, 5/16" - 18 x 1 1/2", Gr 5

1шт.

25-114

NUT,1/4"-28, G5

HEX NUT, 1/4" N.F.

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

27618D

LOOM CLAMP RING

2шт.

29337D

LOOM, switch to generator cable

1шт.

39636DX

CABLE, Serial Range: (Switch-generator)

1шт.

45640DB

LAMP

LIGHT (For components, see detail list under "Headlight and Rear Light" unit)

3шт.

220068

HEX NUT, 1/2" N.C.

3шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

3шт.

49069D

SPACER

LIGHT SPACER

3шт.

51063DA

SCREW

INSTRUMENT PANEL MACHINE SCREW

2шт.

225-10108

NUT,#8-32

2шт.

492-11008

LOCK WASHER,#8

Washer, Lock, #8

2шт.

51675DC

HEADLIGHT SUPPORT PIPE AND PLATE

1шт.

51765DAX

ELECTRICAL INSTRUMENT MOUNTING PANEL COVER

1шт.

425-115

NUT,5/16"-24, G5

HEX NUT, 5/16" N.F.

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

52062D

GROMMET

electrical instrument mounting panel cover

1шт.

42865D

GROMMET, electrical instrument mounting panel cover

1шт.

52973DA

HARNESS

headlight cable (Optional with 365022R91)

1шт.

56273D

CLIP (For 5/16" bolt) (Order 60937D) (S/N 501 to)

1шт.

179814

SPACER

1шт.

9635082

NUT,5/16" - 18, Gr 5

1шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

56276D

CLIP (For 7/16" bolt)

2шт.

59468D

HEADLIGHT SUPPORT U-BOLT

2шт.

103026

NUT,3/8"-24, G5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

60937D

LOOM CLIP, 1/4" (For 1/4" bolt)

2шт.

179793

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd

1шт.

13000R1

HEX NUT, 1/4" N.C.

1шт.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

1шт.

61257D

CABLE, switch to fuse block (S/N 501 to)

1шт.

61262DX

INSTRUMENT PANEL WITH TRANSFER (S/N 501 to)

1шт.

61279D

GENERATOR PULLEY NUT

1шт.

61280DA

GENERATOR BRACE

1шт.

179816

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

1шт.

61284D

BELT

GENERATOR BELT

1шт.

61519DX

CABLE, switch to generator (S/N 501 to)

1шт.

61875D

GENERTOR (Bosch "No-Battery" type) (Bosch ARTF-75-6-900-A16) (No longer supplied for service)

1шт.

62130D

GENERATOR, 61875D, with bracket, 9173DA, and brace 62180DA (Will work for 26086D) (No longer supplied for service)

1шт.

62132D

GENERATOR BRACKET, 9173DA, and brace, 61280DA (Will work for 9173D and 61280D)

1шт.

66836D

REAR LIGHT SUPPORT, 9231DA with screw, 179874 (S/N 501 to)

1шт.

7472H

FUSE BLOCK (S/N 501 to)

1шт.

100751

SCREW,Slotted Rd Hd, #8-32 x 1/2"

SLOTTED SCREW, no. 8-32 x 1/2" (Round head)

1шт.

225-10108

NUT,#8-32

1шт.

492-11008

LOCK WASHER,#8

Washer, Lock, #8

1шт.

350920R1

CLAMP

LIGHT CLAMP (Will workfor 6780D)

3шт.

351794R1

REAR LIGHT CABLE CLIP

1шт.

352797R11

INSTRUMENT PANEL WITH TRANSFER

1шт.

LIGHTING SWITCH, complete (Delco-Remy 1994036) (For components see detail list of parts under "Lighting Switch" unit)

1шт.

353642R11

REAR LIGHT SUPPORT (Optional with 9231DA)

1шт.

179871

BOLT,Hex, 7/16" - 14 x 3 1/4", Gr 5

CAP SCREW, 7/16 x 3-1/4" N.C. hex head

1шт.

355097R1

LOOM CLIP, 1/4" (For 3/8" bolt)

5шт.

179839

BOLT,Hex, 3/8" - 16 x 1", Gr 5

1шт.

280136

NUT,3/8"-16, G8

1шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

358114R91

CABLE, switch to rear light (Will work for 61886D)

1шт.

365022R91

HARNESS, headlight cable (Optional with 52973DA)

1шт.

NLS

NO LONGER SERVICED

HEADLSS SET SCREW, 1/4 x 7/8" N.C. (Dog point)

1шт.

106653

FUSE

(Cartridge type SFE-20) (6 volt, 20 amps.) (Same as 10815VA)

1шт.

179874

BOLT,Hex, 7/16" - 14 x 4", Gr 5

1шт.

114501

JAM NUT,Jam, 1/4"-20, G5

1шт.

LIGHTING SWITCH, complete (Delco-Remy 1994021) (For components see detail list of parts under "Lighting Switch" unit) (S/N 501 to)

1шт.
