Артикул
Название
Примечание
Количество
1
356936R91
GENERATOR
GENERATOR WITH RELAY, 46412D, complete (Will work for 45634D) (Magneto ignition) (S/N, Serial Range: 501-340953)
1шт.
1
356937R91
GENERATOR
GENERATOR, complete (Delco-Remy 1101423) (S/N, Serial Range: 501-340953)
1шт.
1
103821A1R
REMAN-GENERATOR
Generator
1шт.
1
103821A1C
CORE-GENERATOR
Return Part Number
1шт.
1
87497945R
REMAN-ALTERNATOR
Kit to convert reman generator 103821R to an alternator. Kit includes: instruction sheet, hardware kit, 12 v. resistor ballast, wire harness, mounting brkt., tension brkt., reman alternator 12 volt 63 amp w/pulley & regulator.
1шт.
1
103821A1C
CORE-GENERATOR
Return Part Number
1шт.
1
104026A1R
REMAN-GENERATOR
Remanufactured Generator, 6 volt 11 ampere
1шт.
1
104026A1C
CORE-GENERATOR
Return Part Number, Generator, 6 volt 11 ampere
1шт.
179819
BOLT,Hex, 5/16" - 18 x 1 1/8", Gr 5
BOLT, Hex, 5/16"-18 x 1 1/8", G5
2шт.
102644
SLOTTED NUT,5/16"-24, G5
CASTELLATED HEX NUT, 1/2" N.F.
1шт.
9635082
NUT,5/16" - 18, Gr 5
NUT, 5/16"-18, G5
2шт.
Q1520
WASHER
STEEL WASHER, 17/32" I.d. x 1" O.D. x no. 14 ga.
1шт.
103374
COTTER PIN,3/32" x 1"
Pin, Split (Cotter), 3/32" x 1"
1шт.
126-111
WOODRUFF KEY,#5, 1/8" x 5/8", HT
WOODRUFF KEY no. 5, 1/8 x 5/8" (Same as 7699TM)
1шт.
1a
354237R91
SPARE PART GENERATOR, complete (Delco-Remy 1100501) (Battery ignition) (For components see detail list of parts under generator) (S/N 340954 up)
1шт.
179819
BOLT,Hex, 5/16" - 18 x 1 1/8", Gr 5
BOLT, Hex, 5/16"-18 x 1 1/8", G5
2шт.
220065
HEX NUT, 5/16" N.C.
2шт.
139679H
LOCKWASHER, 23/32"
1шт.
2
50384
GENERATOR BRACKET
1шт.
413-716
BOLT,Hex, 7/16" - 14 x 1", Gr 5
CAP SCREW, 7/16 x 1" N.C. hex head
2шт.
103322
LOCK WASHER,7/16"
WASHER, LOCK, 7/16"
2шт.
3
126-111
WOODRUFF KEY,#5, 1/8" x 5/8", HT
FOLLOWS REFERENCE NO. 1
1шт.
4
48877D
SPARE PART GENERATOR BRACE
1шт.
179816
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
BOLT, Hex, 5/16"-18 x 3/4", G5, Full Thd
2шт.
5
6746DX
HUB
GENERATOR PULLEY FLANGE, with screw, 102820 and nut, 218436
1шт.
6
6745DA
HUB
SPARE PART GENERATOR PULLEY HUB
1шт.
7
46412D
GENERATOR
GENERATOR RELAY (Delco-Remy 1116766) (Magneto ignition) (S/N, Serial Range: 501-340953)
1шт.
132900
BOLT,Sl Rnd Hd, #10 - 32 x 3/8"
SLOTTED SCREW, no. 10-32 x 3/8" round head (Cadmium plated)
2шт.
138479
PLUG
LOCKWASHER, no. 10 (External tooth) (Cadmium plated)
2шт.
120391
WASHER,#10
WASHER, 7/32" I.D. x 1/2" O.D. x no. 18 ga. (Cadmium plated)
2шт.
8
ARMATURE SHAFT NUT (Delco-Remy 1914308)
1шт.
9
48878D
V-BELT,0.50" W
Generator
1шт.
9
48878DGV
BELT
Value, V-Belt
1шт.
10
360898R91
REGULATOR
VOLTAGE REGULATOR (Delco-Remy 1118780) (Battery ignition) (Will work for 354234R91) (S/N 340954 up)
1шт.
179789
BOLT,Hex, 1/4" - 20 x 3/8", Gr 5, Full Thd
BOLT, Hex, 1/4"-20 x 3/8", G5, Full Thd
2шт.
103319
LOCK WASHER,1/4"
WASHER, LOCK, 1/4"
2шт.
358162R1
SPARE PART VOLTAGE REGULATOR MOUNTING BRACKET (Not illustrated) (S/N 391358 up)
1шт.
179860
BOLT,Hex, 7/16" - 14 x 1 1/4", Gr 5
CAP SCREW, 7/16" x 1-1/4" N.C. hex head
2шт.
103322
LOCK WASHER,7/16"
WASHER, LOCK, 7/16"
2шт.
NLS
NO LONGER SERVICED
SET SCREW, 1/4 x 7/8" N.C. headless (Dog point)
1шт.
Выбрано товаров: 44
