Запчасти Case IH FARMALL H (063) - ELECTRICAL SYSTEM, STARTING SWITCH, DELCO-REMY (06) - ELECTRICAL SYSTEMS

STARTING SWITCH, assembly (Mfr. no. 1918405)

1шт.

HEX NUT, 3/8" N.C. (Cadmium plated) (Mfr. no. 134566)

1шт.

Not part of starting switch

1шт.

SLOTTED SCREW, no. 10-32 x 1/4" N.C. round head (Cadmium plated) (Mfr. no. 132892)

2шт.

LOCKWASHER, no. 10 (Mfr. no. 106497)

2шт.

LOCKWASHER, 3/8" (Mfr. no. 110730)

1шт.

Not part of starting switch

1шт.

1

STARTING SWITCH LEVER (Mfr. no. 1918322)

1шт.

2

SWITCH LEVER PIN (Mfr. no. 1880254)

1шт.

COTTER PIN, 1/16 x 7/16" (Mfr. no. 137130)

1шт.

3

SWITCH TERMINAL PLAIN WASHER (Mfr. no. 142186H)

1шт.

Not part of starting switch

1шт.

4

SWITCH (Order 1918405)

1шт.

5

816911

STARTING SWITCH INSULATION (Side) (Mfr. no. 816911)

2шт.

6

STARTING SWITCH GASKET (Mfr. no. 1912376)

1шт.

Not part of starting switch

1шт.
