Запчасти Case IH FARMALL CUB (08-22) - ELECTRICAL, COMBINATION REAR LIGHT AND TAIL LIGHT, SEALED BEAM, 12 VOLT (06) - ELECTRICAL

Схема запчастей Case IH FARMALL CUB - (08-22) - ELECTRICAL, COMBINATION REAR LIGHT AND TAIL LIGHT, SEALED BEAM, 12 VOLT (06) - ELECTRICAL
4
5
1
3
2
7
6

Артикул

Название

Примечание

Количество

1

377102R92

LIGHT ASSY, combination rear and tail, 12 volt, only serviceable items are sealed beam unit, 371461R92 and lamp, 455490

1шт.

102637

NUT,1/2"-13, G5

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

2

371461R92

LAMP

UNIT, sealed beam, 12 volt

1шт.

3

455490

BULB,C-6, #1003, 12V, .94W

LAMP, no. 1003, 12 volt

1шт.

4

387403R91

CABLE

ASSY, combination rear light connector

1шт.

5

365503R1

SPACER

rear light

1шт.

6

352121R21

BRACKET

ASSY, rear light

1шт.

120376

NUT,5/16"-18, G5

2шт.

180077

BOLT,Hex, 5/16" - 18 x 3/4", Gr 5

SCREW, 5/16-18 x 3/4 znd hex-hd cap

2шт.

80681

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

7

350920R1

CLAMP

rear light

1шт.

375376R1

RING

GASKET, sealed beam unit, used only if unit is loose in light body

1шт.

Выбрано товаров: 13
