Запчасти Case IH FARMALL C (079) - ELECTRICAL SYSTEM, COMBINATION REAR LIGHT AND TAIL LIGHT ATTACHMENT (06) - ELECTRICAL SYSTEMS

1

361985R93

LAMP

LIGHT, rear, combination and tail light (6 volt) (Will work for 355910R91)

1шт.

2

355423R91

KNOB, switch, w/screw (Metal) (Used with switch body with 5/16" shaft)

1шт.

3

359773R91

KNOB, switch (Plastic) (Used with body with 15/32" shaft)

1шт.

4

355425R1

NUT, retaining, switch

1шт.

5

359682R91

SWITCH

light, w/knob, 359773R91 and nut, 355425R1 and two screws (Less cables) (Will work for 354309R91 and 355424R91)

1шт.

6

BODY, rear light (Not serviced separately-order light assembly)

1шт.

7

356590R91

REFLECTOR, rear light, w/socket

1шт.

8

142309

PULLEY

no. 1133 (6 volt)

1шт.

9

53527D

GASKET

rear light

1шт.

10

350478R1

LENS

rear light

1шт.

11

53525DA

MOLDING

MOULDING, rear light

1шт.

12

53526D

SCREW

rear light door

1шт.

13

356592R91

JEWEL, assembly

1шт.

14

115273

LAMP, no. 51 (6 volt)

1шт.

15

79408H

SPRING, retaining, terminal

1шт.

16

79407H

PLATE

terminal

1шт.

174-211

SCREW,Sl Rnd Hd, #8 - 32 x 5/16"

slotted-rd-hd., cd-pltd., no. 8-32 NC x 5/16"

2шт.

138530

LOCK WASHER,Int Tooth, #8

WASHER, LOCK, Int Tooth, #8

2шт.

17

356591R91

SOCKET, w/cable (Switch to red light)

1шт.

18

354304R91

CABLE, socket to switch, w/spring

1шт.

19

354303R91

CABLE, switch to terminal plate

1шт.

68417D

INSULATOR

PACKAGE, terminal plate, assembly, Consists of

1шт.

79407H

PLATE

1шт.

174-211

SCREW,Sl Rnd Hd, #8 - 32 x 5/16"

2шт.

79408H

SPRING

1шт.

138530

LOCK WASHER,Int Tooth, #8

WASHER, LOCK, Int Tooth, #8

2шт.
