Запчасти Case IH FARMALL BN (072) - CHASSIS, RADIATOR, GRILLE AND HOOD (12) - CHASSIS

Схема запчастей Case IH FARMALL BN - (072) - CHASSIS, RADIATOR, GRILLE AND HOOD (12) - CHASSIS
4
18
3
14
11
17
10
16
8
10
2
15
7
9
13
9
1
6
5
12

Артикул

Название

Примечание

Количество

1

43658D

DECAL

NAME PLATE (Farmall), Start Serial: 501

1шт.

1

43658DGV

EMBLEM

Value, Name Plate

1шт.

.

350516R1

SCREW, no. 7 x 3/8" flat head

2шт.

1

352580R1

PRODUCT GRAPHIC

NAME PLATE (IH), up

1шт.

.

352581R1

SLOTTED SCREW, no. 6 x 1/2" countersunk flat head

1шт.

2

51110DX

RADIATOR GRILLE, complete ("A" only), Serial Range: 501-41329

1шт.

2

52963DX

RADIATOR GRILLE, complete ("B" and "BN"), Serial Range: 501-40192

1шт.

2

58139DAX

RADIATOR GRILLE, complete (not "B" or "BN"), 41330 up

1шт.

2

58140DAX

RADIATOR GRILLE, complete ("B" and BN"), 40193 up

1шт.

3

51149DBX

RADIATOR, complete

1шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

58124DBX

RADIATOR, complete, less cap

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

120702

ELBOW,45 Degree, 3/8" NPT Street

STREET ELBOW, 3/8" x 45deg. (B and BN only)

1шт.

4

43983D

CAP

RADIATOR CAP, with gasket, 43984D

1шт.

4

43983DGV

RADIATOR CAP

Value, Radiator Cap

1шт.

5

43984D

GASKET

RADIATOR CAP GASKET

1шт.

6

50237DAX

FAN HOUSING

1шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

16242R1

CAP SCREW, 1/4 x 3-1/2" N.F. hex head

4шт.

.

25-114

NUT,1/4"-28, G5

HEX NUT, 1/4" N.F.

4шт.

.

103319

LOCK WASHER,1/4"

WASHER, LOCK, 1/4"

4шт.

6

58130D

FAN HOUSING

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

186304

BOLT,Hex, 5/16" - 24 x 3 1/2", Gr 5

CAP SCREW, 5/16 x 3-1/2" N.F. hex head

2шт.

.

217220

CAP SCREW, 5/16 x 3-3/4" N.F. hex head

2шт.

.

425-115

NUT,5/16"-24, G5

HEX NUT 5/16" N.F.

4шт.

.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

4шт.

7

51003D

RADIATOR BRACE

1шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

181331

BOLT,Hex, 5/16" - 24 x 1/2", Gr 5

CAP SCREW, 5/16 x 1/2" N.F. hex head

2шт.

.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

.

95-11034

WASHER,1/4"

11/32" I.D. x 3/4" O.D. x no. 16 ga

2шт.

7

359170R11

RADIATOR BRACE (will work for 58129D)

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

1шт.

8

58141D

RADIATOR GRILLE FASTENER SCREW

3шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

9

20075D

HOSE

RADIATOR HOSE, 2" I.D x 2-1/4" long, 3 ply

2шт.

10

357870R91

CLAMP

RADIATOR HOSE CLAMP, (will work for 29970D and 91406HA)

4шт.

11

47232DA

RADIATOR MOUNTING STUD

2шт.

.

120370

HEX NUT, 7/16" N.F. (cadmium plated)

2шт.

.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

2шт.

12

47240D

PAD

RADIATOR PAD

2шт.

13

50958D

SPRING

HOOD FASTENER SPRING

4шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

RIVET, 1/8 x 7/32 x 9/32" head (tubular)

8шт.

13

50958D

SPRING

RADIATOR GRILLE FASTENER SPRING

3шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

104051

RIVET, 1/8 x 1/4" (round head) But Hd, 1/8" x 1/4"

6шт.

14

50957D

FASTENER

HOOD FASTENER

4шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

14

50957D

FASTENER

RADIATOR GRILLE FASTENER

3шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

15

48707D

HOOD CLAMP HOOK SPRING

4шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

16

51144DX

HOOD WITH FASTENERS, 50957D (gasoline)

1шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

16

58144DX

HOOD WITH CLAMP BRACKETS (gasoline)

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

16

58145DX

HOOD WITH BRACKET (kerosene or distillate)

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

16

51148DX

HOOD WITH BRACKET (kerosene or distillate)

1шт.

"B" and "BN" - 501 to 40192, "A", "AV", 41330 up

1шт.

.

58147D

CLAMP

HOOD CLAMP HANDLE WITH HOOK, R.H. (Used at right rear and left front of hood)

2шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

Q391

WASHER

9/32" I.D. x 5/8" O.D. x no. 18 ga

2шт.

.

432-68

COTTER PIN,3/32" x 1/2"

Pin, Split (Cotter), 3/32" x 1/2"

2шт.

17

60754D

CLAMP

HOOD CLAMP, R.H., rear with bracket (kerosene or distillate)

1шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

58146D

CLAMP

HOOD CLAMP HANDLE WITH HOOK, L.H. (Used at left rear and right front of hood)

2шт.

"B" and "BN" - 40408 up, "A", "AV", - 41405 up

1шт.

.

Q391

WASHER

9/32" I.D. x 5/8" O.D. x no. 18 ga

2шт.

.

432-68

COTTER PIN,3/32" x 1/2"

Pin, Split (Cotter), 3/32" x 1/2"

2шт.

Выбрано товаров: 77
