Запчасти Case IH 706 (K-12) - DRAWBARS AND HITCHES, THREE POINT HITCH Drawbars & Hitches

NSS

NOT SOLD SEPARAT

ATTACHMENT, three point hitch, 398362R91, will work for 396743R91, tractors with draft control and draft sensing, Farmall tractors

1шт.

NSS

NOT SOLD SEPARAT

ATTACHMENT, three point hitch, 398364R91, will work for 396745R91, tractors with draft control and draft sensing, International tractors

1шт.

1

382156R11

ARM

ASSY, rockshaft

2шт.

2

383357R1

BUSHING,28.56mm ID x 33.38mm OD x 63.5mm L

rockshaft arm

2шт.

3

86504104

LUBE NIPPLE,1/4" x .56" lg, Drive

FITTING, 1/4 drive type st.r lub.

6шт.

4

397095R1

SPARE PART

SCREW ASSY, LH leveling, Farmall tractors

1шт.

4

397093R1

SCREW ASSY, LH leveling, International tractors

1шт.

Q3482

WASHER

1-5/32 x 1-3/4 x 11 ga.

1шт.

520175R1

CLIP

PIN, quick attachable cot.

1шт.

113020

SET SCREW,Sq Hd, 5/8"-11 x 1"

SCREW, 5/8 x 1 sq-hd. cone-pt. set

1шт.

5

397096R1

SPARE PART

SCREW ASSY, RH leveling, Farmall tractors

1шт.

5

397094R1

SPARE PART

SCREW ASSY, HR leveling, International tractors

1шт.

Q3482

WASHER

1-5/32 x 1-3/4 x 11 ga.

1шт.

520175R1

CLIP

PIN, quick attachable cot.

1шт.

113020

SET SCREW,Sq Hd, 5/8"-11 x 1"

SCREW, 5/8 x 1 sq-hd. cone-pt. set

1шт.

6

396752R1

HOUSING

leveling screw

2шт.

19791R1

PIN,1/4" x 1 1/8", Coiled

1/4" x 1-1/8", coiled

1шт.

7

523861R2

HANDLE

HANDLE, leveling screw

2шт.

617939R1

PIN,5/16" x 1 1/2", Coiled

5/16" x 1-1/2", coiled

2шт.

8

392915R1

AXLE PIN

PIN, leveling screw housing

2шт.

432-1624

COTTER PIN,1/4" x 1 1/2"

Pin, Split (Cotter), 1/4" x 1 1/2"

2шт.

9

398249R91

LINK W/BUSHING, front section lower LH, will work for 396759R1

1шт.

10

398250R91

LINK W/BUSHING, front section lower RH, will work for 396760R1

1шт.

11

382193R1

SPRING

stiffener

2шт.

181331

BOLT,Hex, 5/16" - 24 x 1/2", Gr 5

SCREW, 5/16-24 x 1/2 hex-hd. cap

2шт.

12

382192R1

SPRING

lower link latch

2шт.

13

382191R2

LOCK ASSY

LATCH, lower link

2шт.

14

383361R1

BUSHING

front lower link ball

2шт.

15

219-8

LUBE NIPPLE,1/4" - 28 NPTF

NIPPLE, LUBE, , Straight 1/4"-28 NPT x .54" lg

2шт.

16

406685R1

PIN,25.4mm OD x 101.6mm L

lower link, also furnish retainer 406687R1, will work for 382194R2

1шт.

179882

PIN

SCREW, 1/2-13 x 1-1/8 hex-hd. cap

2шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

2шт.

395-11053

WASHER,0.53" ID x 1.06" OD x 0.1" Thk

17/32 x 1-1/16 x .095 (or as required)

2шт.

17

384025R1

BRACKET

lockout, not included in three-point hitch attachment

2шт.

413-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 5

SCREW, 5/8-11 x 2 hex-hd. cap

6шт.

18

378404R1

FASTENER

CLIP, upper link storage bracket

1шт.

179837

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

19

378403R1

ELECTRICAL WIRE

BRACKET, upper link storage

1шт.

20

383330R1

GASKET

draft control adj opening cover

1шт.

21

382212R11

BRACKET

ASSY, upper link

1шт.

20661R1

BOLT,Hex, 5/8" - 11 x 2", Gr 8

SCREW, 5/8-11 x 2 hex-hd. cap

6шт.

22

382210R11

PIN

ASSY, upper link bracket

1шт.

23

520175R1

CLIP

PIN, quick attachable cot.

1шт.

24

392204R1

HANDLE

upper link turnbuckle

1шт.

25

386049R91

LINK

SCREW ASSY, RH thread, optional with 384849R11 & 393460R11

1шт.

25

384849R11

LINK

SCREW ASSY, RH thread, optional with 386049R91 & 393460R11

1шт.

25

393460R11

NO LONGER SERVICED

SCREW ASSY, RH thread, optional with 386049R91 & 384849R11

1шт.

25

395033R1

SCREW

ASSY, RH thread, heavy duty

1шт.

26

384850R11

TURNBUCKLE

ASSY, upper link, for service replacement, furnish turnbuckle 400908R1, pin SB191, and pin 520175R1

1шт.

26

400908R1

TURNBUCKLE

ASSY, upper link

1шт.

520175R1

CLIP

PIN, quick attachable cot.

1шт.

26

395036R1

TURNBUCKLE ASSY, upper link, heavy duty

1шт.

27

395108R1

CLIP

turnbuckle handle spring, used with 384850R11

1шт.

27

395026R1

CLIP, turnbuckle handle spring, heavy duty

1шт.

28

SB191

HEADED PIN,3/8" x 1 3/4"

PIN, 3/8 x 1-3/4 std-hd., upper link turnbuckle handle

1шт.

107763

COTTER PIN,1/8" x 5/8"

PIN, SPLIT (COTTER), 1/8" x 5/8"

1шт.

29

386048R91

LINK

SCREW ASSY, LH thread, optional with 384848R11 & 393459R11

1шт.

29

384848R11

LINK

SCREW ASSY, LH thread, optional with 393459R11 & 386048R91

1шт.

29

393459R12

STRUT

SCREW ASSY, LH thread, optional with 384848R11 & 386048R91

1шт.

29

395030R1

SCREW

ASSY, LH thread, heavy duty

1шт.

30

517758R91

SPLIT PIN/SAFETY PIN

PIN, implement pin retaining

1шт.

31

380563R91

PIN

ASSY, upper link implement

1шт.

32

400907R92

LINK

ASSY, upper, will work for 384851R92

1шт.

32

404631R91

NO LONGER SERVICED

LINK ASSY, upper, heavy duty, replaces 395028R91

1шт.

33

384852R1

AXLE PIN

PIN, stabilizer

4шт.

108638

COTTER PIN,3/16" x 1 1/8"

Pin, Split (Cotter), 3/16" x 1 1/8"

4шт.

34

382386R2

ARM

stabilizer control

1шт.

35

382390R1

BOLT (SPREADER),1 1/4" - 7 x 2.38"

EYEBOLT, stabilizer front

2шт.

36

406243R1

YOKE

HOUSING ASSY, lateral limiter, will work for 383358R11

2шт.

37

383363R11

AXLE PIN

PIN ASSY, lockout

2шт.

38

386198R1

STUD

lateral limiter, Farmall tractors

2шт.

38

386199R1

STUD

lateral limiter, International tractors

2шт.

527374R1

AXLE PIN,12.7mm OD x 57.15mm L

PIN, 1/2 x 2-1/4 headed

2шт.

364436R1

PIN,3/16" x 1", Coiled

2шт.

496-21066

WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk

21/32 x 1-5/16 x .095

2шт.

39

406244R1

YOKE

ASSY, limiter, will work for 386200R91

2шт.

40

382397R1

BOLT,3/4" - 16 x 2", Drilled

EYEBOLT, stabilizer rear

2шт.

427639

SLOTTED NUT,3/4"-16, G5

NUT, 3/4-16 slt hex

2шт.

32-822

COTTER PIN,1/8" x 1 3/8"

PIN, split (Cotter), 1/8" x 1-3/8"

2шт.

41

383362R2

AXLE PIN,25.4mm OD x 106.68mm L

SHAFT, stabilizer control arm

2шт.

616252R1

LOCK PIN,3/8" x 2 1/8", Slotted

PIN, 3/8" x 2-1/8", slotted

2шт.

427651

SLOTTED NUT,1"-14, G5

NUT, 1-14 slt hex

2шт.

119179

PIN, 3/16 x 1-7/8 cot.

2шт.

42

400713R1

SUPPORT

drawbar, will work for 383385R1

1шт.

271562

SHIELD,Hex, 5/8" - 11 x 2", Gr 5

SCREW, 5/8-11 x 2 hex-hd. cap

8шт.

43

400714R1

BAR

PLATE, drawbar support, will work for 382198R1

1шт.

271612

BOLT,Hex, 3/4" - 10 x 2 1/4", Gr 5

SCREW, 3/4-10 x 2-1/4 hex-hd. cap

4шт.

44

398371R11

DRAG LINK

LINK ASSY, rear section lower LH, will work for 382189R11

1шт.

20126R1

PIN,1/2" x 2", Coiled

1шт.

45

517758R91

SPLIT PIN/SAFETY PIN

PIN ASSY, drawbar, will work for 385159R91

2шт.

46

374150R1

DRAWBAR

cross, not included in three-point hitch attachment

1шт.

47

398372R11

DRAG LINK

LINK ASSY, rear section lower RH, will work for 382188R11

1шт.

20126R1

PIN,1/2" x 2", Coiled

1шт.

48

404787R1

SHIELD

linch pin

2шт.

49

406687R1

RETAINER

lower link pin

2шт.

381039R91

PARTS ACCESSORY, three point hitch cross drawbar, consists of (2) bracket 384025R1, (1) drawbar 374150R1 (6) screw 271562

1шт.

380579R91

BUSHING

PARTS ACCESSORY, bushing & pin adapter, for use w/category I implements when mounting on category II hitch, consists of:

1шт.

380581R1

BUSHING

upper link category #1 short

1шт.

380582R1

BUSHING

upper link category #1 long

1шт.

380583R1

BUSHING

lower link category #1 short

2шт.

380584R1

BUSHING

lower link category #1 long

2шт.

380580R91

PIN

ASSY, upper link implement

1шт.

11484R

BUSHING

SPACER, lower long bushing

2шт.
