Запчасти Case IH 460 (215) - DRAWBARS & HITCHES, ROCKSHAFT DRIVE UNIT Drawbar & Hitches

a

372855R92

SPARE PART UNIT, rockshaft drive

1шт.

Letters of these units correspond with those shown following the description of the parts in the list and identifies the unit for which the part is used. Items without letters after the description indicate that the part is used for all units.

1шт.

b

372856R92

SPARE PART UNIT, rockshaft drive

1шт.

Letters of these units correspond with those shown following the description of the parts in the list and identifies the unit for which the part is used. Items without letters after the description indicate that the part is used for all units.

1шт.

c

372857R92

SPARE PART UNIT, rockshaft drive

1шт.

Letters of these units correspond with those shown following the description of the parts in the list and identifies the unit for which the part is used. Items without letters after the description indicate that the part is used for all units.

1шт.

1

373619R91

SPARE PART ASSEMBLY, drive unit

1шт.

2

373622R1

SPARE PART COVER, drive unit

1шт.

3

372776R1

SPARE PART RING, drive unit coupling snap

1шт.

4

372774R1

SPARE PART

1шт.

4

373621R1

SPARE PART

1шт.

5

372773R1

SPARE PART Drive unit

1шт.

6

31385D

SPARE PART Drive unit coupling

1шт.

7

373595R91

SPARE PART

1шт.

7

373620R91

SPARE PART

1шт.

8

355966R1

O-RING,0.424" ID x 0.103" Width

1шт.

9

373594R91

SPARE PART ASSEMBLY, drive

1шт.

10

373593R91

SPARE PART W/BUSHING ASSEMBLY, control

1шт.

11

373599R91

SPARE PART

1шт.

11

373600R91

SPARE PART

1шт.

11

373601R91

SPARE PART

1шт.

12

373605R91

SPARE PART ASSEMBLY, drive unit (Unit A)

1шт.

12

373606R91

SPARE PART ASSEMBLY, drive unit (Unit B)

1шт.

12

373607R91

SPARE PART ASSEMBLY, drive unit (Unit C)

1шт.

373623R91

SPARE PART

1шт.

373622R1

SPARE PART COVER

1шт.

373621R1

SPARE PART

1шт.

373620R91

SPARE PART ASSEMBLY

1шт.

373594R91

SPARE PART ASSEMBLY)

1шт.
