Запчасти Case IH 460 (155) - WHEELS, DUAL FRONT WHEELS CONVERSION PACKAGE, ALL FARMALL 460 SERIES TRACTORS EXCEPT HI-CLEAR MODELS (11) - WHEELS

Схема запчастей Case IH 460 - (155) - WHEELS, DUAL FRONT WHEELS CONVERSION PACKAGE, ALL FARMALL 460 SERIES TRACTORS EXCEPT HI-CLEAR MODELS (11) - WHEELS

Артикул

Название

Примечание

Количество

370382R91

SPARE PART PARTS ACCESSORY, lower bolster with pneumatic tire variable thread front wheel, may be used to equip cotton picker tractors having other front wheel equipment with dual front wheels for other farm operations

1шт.

Pneumatic tires and inner tubes should be ordered from the manufacturer.

1шт.

The following parts are also listed and illustrated with related units.

1шт.

51485D

BOLT,9/16" - 18 x 1 7/32"

Front wheel mounting

12шт.

369855R11

SPARE PART ASSEMBLY, lower

1шт.

SCREW, 3/4 x 2" hex-hd. cap

4шт.

369859R1

CAP

Front wheel hub

2шт.

SCREW, 5/16 x 5/8" hex-hd. cap

6шт.

WASHER, 5/16" lock

6шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

Front wheel inner bearing

2шт.

371882R91

ROLLER BEARING,20.64mm ID x 49.23mm OD x 19.84mm W

Front wheel outer roller

2шт.

369860R1

GASKET,0.79mm Thk

Front wheel hub cap

2шт.

369858R11

HUB

ASSEMBLY, front wheel

2шт.

427639

SLOTTED NUT,3/4"-16, G5

Front wheel

2шт.

48539DA

PACKING RING

OIL SEAL, front wheel

2шт.

369857R1

WASHER,20.7mm ID x 31.75mm OD x 3mm Thk

Front wheel outer bearing retainer

2шт.

361714R91

WHEEL ASSY.

Front (Disc type 4.25 KA-16DC Rim for 6.00-16 or 6.50-16 tire)

2шт.

371417R92

BEARING

KIT, applications: IH tractor models 460, 504, 544, 2504, 2544, 606, 2606, 656, 2656, consists of the following seven parts

1шт.

371882R91

ROLLER BEARING,20.64mm ID x 49.23mm OD x 19.84mm W

1шт.

371883R1

BEARING CUP

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

1шт.

618024R1

BEARING CUP,65.113mm OD x 13.97mm W

1шт.

369860R1

GASKET,0.79mm Thk

1шт.

48539DA

PACKING RING

SEAL

1шт.

48548D

WASHER

1шт.

371418R92

BEARING SET,34.93mm ID x 77.79mm OD

KIT, applications: IH tractor models 460, 560, 660, 544, 644, 2544, 06 series, 56 series, 66 series, 86 series, 30 series and 50 series, consists of the following seven parts

1шт.

618023R91

BEARING ASSY,34.93mm ID x 18.2mm W

1шт.

G15215

ROLLER BEARING

1шт.

618024R1

BEARING CUP,65.113mm OD x 13.97mm W

1шт.

619387R1

BEARING CUP

1шт.

369860R1

GASKET,0.79mm Thk

1шт.

370254R91

OIL SEAL,57.02mm ID x 82.55mm OD x 6.86mm Thk

1шт.

48703D

RETAINER

1шт.

Выбрано товаров: 33
