Запчасти Case IH 460 (178) - HYDRAULIC SYSTEM, HYDRAULIC EQUIPMENT, LIST OF PARTS (07) - HYDRAULIC SYSTEM

366064R1

CONNECTOR, ELEC

CONNECTOR swivel, 7/8-14 male and 1/2" female pipe thread union

1шт.

372413R91

CONNECTOR, ELEC

CONNECTOR swivel, 1/2" male pipe thread to 7/8-14 female straight thread

1шт.

371111R91

COUPLING

break-away (Rear section)

1шт.

371113R91

SPARE PART self-sealing, male and female

1шт.

371292R91

HYDRAULIC CYLINDER

hydraulic (3-1/2 x 8") (For components see list of parts under details of "Hydraulic Cylinders")

1шт.

461166R91

HOSE ASSY.

hydraulic break-away coupling to cylinder (1/2ID x 100" long)

1шт.

372432R91

HOSE

hydraulic cylinder (1/2 ID x 96" long)

1шт.

372433R91

SPARE PART hydraulic cylinder (1/2 ID x 60" long)

1шт.
