(466) - ATTACHMENTS, DUAL FRONT WHEELS CONVERSION PACKAGE, SPECIAL, FOR ALL TRACTORS EXCEPT HI-CLEAR MODELS

Запчасти Case IH 450-SERIES (466) - ATTACHMENTS, DUAL FRONT WHEELS CONVERSION PACKAGE, SPECIAL, FOR ALL TRACTORS EXCEPT HI-CLEAR MODELS Attachments

Схема запчастей Case IH 450-SERIES - (466) - ATTACHMENTS, DUAL FRONT WHEELS CONVERSION PACKAGE, SPECIAL, FOR ALL TRACTORS EXCEPT HI-CLEAR MODELS Attachments
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

364481R91

1шт.

PACKAGE, lower bolster, w/variable tread dual front (pneumatic tire) wheels (may be used to equip cotton picker tractors (having other front wheel equipment) with dual front wheels for other farm operations) (see note A) The following parts are also listed and illustrated with related units.

1шт.

48751DA

BOLT,3/4" - 16 x 2 7/8"

stop, steering

1шт.

6719DDX

BOLSTER, lower, w/axle, rivet, 111280 and two shields, 48701D

1шт.

352536R1

NUT

hex., 3/4-16NF

4шт.

108643

COTTER PIN,5/32" x 1 3/8"

Pin, Split (Cotter), 5/32" x 1 3/8"

2шт.

14-1244

BOLT,Hex, 3/4" - 16 x 2-3/4", Gr 5

SCREW, cap, hex-hd., 3/14-16NF x 2-3/4"

3шт.

103326

LOCK WASHER,3/4"

WASHER, LOCK, 3/4"

4шт.

48546DB

CAP

front wheel hub

2шт.

179814

SPACER

6шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

6шт.

ST781A

TAPERED BEARING,42.88mm ID x 22.48mm W

CONE, front wheel inner bearing

2шт.

365433R91

BEARING

CONE, front wheel outer roller bearing (optional with 367836R91)

2шт.

367836R91

CONE

front wheel outer roller bearing (optional with 365433R91)

2шт.

48547D

GASKET

front wheel hub cap

2шт.

48704DA

OIL SEAL

OIL SEAL, front wheel

2шт.

354246R91

RIM

front wheel (rim size 4.25 KA - 16 DC) (tire size 6.00 or 6.50 or 7.50 x 16)

2шт.

352777R1

NUT

mounting, front wheel rim

6шт.

181784

SCREW, cap, hex-hd., cd-pltd., 5/8-18NF x 3"

6шт.

492-11062

BEARING WASHER,5/8"

WASHER, LOCK, 5/8"

6шт.

131016

WASHER

plain, cd-pltd., 21/32" I.D. x 1-5/16" O.D. x no. 13 ga.

6шт.

8284DBXA

WHEEL, front, assembly (composed of (1) cup 451495R1, (1) cup ST882, (1) hub 8284DB (NSS), (1) retainer 48703D, (1) retainer 60290DA, (1) retainer 60291D)

2шт.

361138R1

NUT

front wheel outer bearing retainer

2шт.

48701D

SHIELD

dust, front wheel

2шт.

48702D

WASHER,57.15mm ID x 82.55mm OD x 4.76mm Thk

felt, front wheel

2шт.

353838R1

WASHER

WASHER, front wheel outer bearing retaining

2шт.
