Артикул
Название
Примечание
Количество
368189R91
PACKAGE, remote control break-away adapter (attaches to right front junction block) (for tractors equipped with Hydra-Touch System) (double or triple valve) (this may be ordered as a complete package or may be assembled from parts stock) (see note A)
1шт.
1
353212R1
SPACER, break-away coupling bracket
1шт.
2
368191R11
BRACKET, break-away coupling, w/pin
1шт.
179874
BOLT,Hex, 7/16" - 14 x 4", Gr 5
1шт.
3
364311R91
COUPLING, front section, hydraulic break-away, assembly (for components see list of parts under details of "Break-Away and Self-Sealing Coupling") (will work for 353215R91)
1шт.
103385
COTTER PIN,1/8" x 1"
PIN, SPLIT (COTTER), 1/8" x 1"
1шт.
395-11053
WASHER,0.53" ID x 1.06" OD x 0.1" Thk
plain, 17/32" ID x 1-1/16" OD x no. 13 ga.
1шт.
19849H
WASHER, plain, 33/64" ID x 1-3/8" OD x no. 11 ga.
2шт.
4
353213R2
SPRING
break-away coupling bracket
1шт.
5
363628R1
ELBOW, street, break-away coupling
2шт.
6
368190R1
BRACKET, hose support
1шт.
7
363726R1
BRACKET, rear, remote control adapter tube support
1шт.
8
368193R91
TUBE, w/hose, inner remote control adapter
1шт.
9
368192R91
TUBE, w/hose, outer, remote control adapter
1шт.
10
363725R1
BRACKET, front, remote control adapter tube support
2шт.
11
363834R1
ANCHOR, brake pedal return spring
1шт.
179835
BOLT,Hex, 3/8" - 16 x 5/8", Gr 5, Full Thd
1шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
1шт.
12
350429R1
O-RING,0.103" Thk x 0.612" ID, -114, Cl 5, 75 Duro
RING, seal, remote control junction block
2шт.
13
363719R1
BLOCK, junction, remote control
1шт.
187234
BRACKET
SCREW, cap, hex-hd., 3/8-24NF x 2-7/8"
2шт.
93-41039
LOCK WASHER,Ext Tooth, 3/8"
WASHER, lock, external-tooth, 3/8" (see note A)
2шт.
14
364148R1
ELBOW
street, remote control block (1/2 x 90deg.)
2шт.
Выбрано товаров: 23
