62973D
PARTS ACCESSORY, air cleaner pipe extension (for carbureted engine tractors)
1шт.
361690R91
AIR INTAKE TUBE
PARTS ACCESSORY, air cleaner pipe extension (for diesel engine tractors)
1шт.
1
62967D
CLAMP, extension pipe brace, lower
2шт.
181364
BOLT,Hex, 3/8" - 24 x 1", Gr 5
SCREW, cap, hex-hd., 3/8-24NF x 1"
2шт.
103321
LOCK WASHER,3/8"
WASHER, LOCK, 3/8"
2шт.
2
62968D
BRACE, extension, pipe, L.H. (for carbureted engine tractors)
1шт.
2
66755D
BRACE, extension, pipe, L.H. complete (for diesel engine tractors)
1шт.
9635082
NUT,5/16" - 18, Gr 5
1шт.
179816
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
1шт.
103320
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
3
62972D
CLAMP, extension, pipe, brace, upper
1шт.
9635082
NUT,5/16" - 18, Gr 5
1шт.
179818
BOLT,Hex, 5/16" - 18 x 1", Gr 5
1шт.
103320
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
4
62971D
EXTENSION, pipe
1шт.
5
62969D
BRACE, extension, pipe, R.H. (for carbureted engine tractors)
1шт.
5
66756D
BRACE, extension, pipe, R.H. (for diesel engine tractors)
1шт.
9635082
NUT,5/16" - 18, Gr 5
1шт.
179816
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
1шт.
103320
LOCK WASHER,5/16"
WASHER, LOCK, 5/16"
1шт.
6
362762R1
INTAKE AIR HOSE,2.25" ID x 2.25", SAE 20R1 Class R
Air Cleaner Pipe 2.25" ID x 2.25", SAE 20R1 Class R
1шт.
7
45813D
CLAMP
extension, pipe, hose
1шт.
8
93082H
NUT
extension, lower brace clamp
2шт.
9
361624R1
PIPE, exhaust (for diesel engine tractors)
1шт.
