Запчасти Case IH 330 (082[A]) - ELECTRICAL SYSTEM, COMBINATION REAR LIGHT AND TAIL LIGHT INTERNATIONAL 330 (06) - ELECTRICAL SYSTEMS

1

361985R93

LAMP

REAR LIGHT AND TAIL LIGHT ASSEMBLY, combination (6 volt) (order 373305R91)

1шт.

2

359773R91

KNOB, switch

1шт.

3

355425R1

NUT, switch retaining

1шт.

4

359682R91

SWITCH

ASSEMBLY, light

1шт.

5

BODY, rear light (not serviced separately, order light assembly)

1шт.

6

356590R91

REFLECTOR ASSEMBLY, rear light

1шт.

7

B50206

LAMP

BULB, no. 1133 (6 volt)

1шт.

8

53527D

GASKET

rear light

1шт.

Item 8. Snap in lens (if needed) is 280579a1.

1шт.

9

350478R1

LENS

rear light

1шт.

10

53525DA

MOLDING

MOULDING, rear light

1шт.

11

53526D

SCREW

rear light door

1шт.

12

356592R91

JEWEL ASSEMBLY

1шт.

13

115273

BULB, no. 51 (6 volt)

1шт.

14

79408H

SPRING, terminal retaining

1шт.

15

79407H

PLATE

terminal

1шт.

SCREW, no. 8 x 5/16" cd-pltd. slt-rd-hd. mach.

2шт.

WASHER, no. 8 cd-pltd. internal tooth lock

2шт.

16

356591R91

SOCKET AND WIRING ASSEMBLY, switch to red light

1шт.

17

354304R91

CABLE AND SPRING ASSEMBLY, Serial Range: socket-switch

1шт.

18

354303R91

CABLE, switch to terminal plate

1шт.

68417D

INSULATOR

PACKAGE ASSEMBLY, terminal plate (consists of, (1) plate 79407H, (1) spring 79408H)

1шт.
