Запчасти Case IH 330 (169) - STEERING MECHANISM, POWER STEERING, INTERNATIONAL 330 Steering Mechanism

1

364875R1

SUPPORT, pressure hose and tube (on reservoir cover screw)

1шт.

2

364887R11

TUBE ASSEMBLY, regulator to valve (units B, C and D) (see note A and B)

1шт.

3

364877R1

ELBOW

BODY, return line tube 90deg. elbow

1шт.

4

369787R11

TUBE ASSEMBLY, return line

1шт.

5

9410976

ELBOW,90 Degree, 9/16"-18, 37 Degree x 9/16"-18, O-Ring

ASSEMBLY, 3/8" 90deg. tubing (o-ring type)

2шт.

6

9410204

HYD CONNECTOR,7/8"-14, 37 Degree x 7/8"-14, O-Ring

CONNECTOR, 5/8" tubing (o-ring type) (units B, C and D) (see note A and B)

1шт.

7

364839R1

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

6-1, 90 Duro, .468" ID x .078" Thk, pressure or return tube

3шт.

8

364872R91

HOSE and TUBE ASSEMBLY, pressure line

1шт.

9

370548R91

GEAR ASSEMBLY, steering (for components see list of parts under details of "Steering Gear") (will work for 364453R95)

1шт.

SCREW, 3/8 x 1-3/8" hex-hd cap

1шт.

354921R1

BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 8

SCREW, steering gear mounting (1-1/2" long)

5шт.

WASHER, 3/8" lock

6шт.

10

350667R1

O-RING,0.103" Thk x 0.674" ID, -115, Cl 5, 75 Duro

hydra-touch control valve (5 for unit A; 8 for unit B; 14 for unit C; 17 for unit D) (see note A)

1шт.

11

364841R96

VALVE ASSEMBLY, regulator safety and flow control (for components see list of parts under details of "Regulator Safety and Flow Control Valve")

1шт.

12

9410202

HYD CONNECTOR,9/16"-18, 37 Degree x 9/16"-18, O-Ring

CONNECTOR, 3/8" tubing (o-ring type)

1шт.

13

364885R1

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

5/8" tube fitting (3/4 x 15/16 x 3/32") (unit A; 2 for unit B; 3 for units C and D)

1шт.

14

9410360

PLUG

regulator safety and flow control valve housing

1шт.

15

364879R1

O-RING,0.103" Thk x 0.862" ID, -118, Cl 5, 75 Duro

control valve cover 97/8 x 1-1/16 x 3/32") (unit B; 2 for unit C and D)

1шт.

16

361457R1

COVER, control valve (unit B)

1шт.

16

364878R1

COVER, control valve (2 for unit C and D) (refer to the Hydra- Touch System for service parts listing for the attaching parts)

1шт.

17

9410978

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring

ASSEMBLY, control valve cover 90deg. (2 for units B, C and D) (o-ring type)

1шт.

18

364888R11

TUBE ASSEMBLY, front view (unit C)

1шт.

19

364889R11

TUBE ASSEMBLY, front view (unit D)

1шт.

20

355967R1

O-RING,0.364" ID x 0.003" Width

lift circuit block plug (for use in Hydra-Touch valve having 1/2" dia. pressure port) (3/8 x 1/2 x 1/16") (units C and D)

1шт.

20

370920R1

O-RING,1/2" ID

lift circuit block plug (1/2 x 5/8 x 1/16") (for use in Hydra-Touch valve 5/8" dia. pressure port) (units C and D)

1шт.

20

574069R1

O-RING,0.750" ID x .062"

circuit block plug (3/4 x 7/8 x 1/16") (for use in Hydra- Touch valve 5/8" dia. pressure port) (units C and D)

1шт.

21

364880R1

PLUG

lift circuit block (for use in Hydra-Touch valve having 1/2" dia. pressure port) (units C and D)

1шт.

21

374392R1

PLUG, lift circuit block (for use in Hydra-Touch valve 5/8" dia. pressure port) (units C and D)

1шт.

22

9410978

ELBOW,90 Degree, 7/8"-14, 37 Degree x 7/8"-14, O-Ring

ASSEMBLY, control valve cover 90deg. (unit B) (see notes A and B)

1шт.

23

9411119

TEE,7/8"-14, 37 Degree x 7/8"-14, O-Ring Br

ASSEMBLY, control valve cover (units C and D) (o-ring type) (see notes A and B)

1шт.

364902R11

BRACKET, voltage regulator mounting (units B, C and D) (see note B)

1шт.

SCREW, 3/8NF x 3/4" hex-hd cap

1шт.

WASHER, 3/8" lock

1шт.

366566R1

CAP

steering wheel monogrammed ("IH Power Steering)

1шт.

372704R1

TRANSMISSION OIL

FLUID, "Hy-Tran" (gallon can) (see note A)

1шт.

372703R1

FLUID, "hy-Tran" (quart can) (see note A)

1шт.

372705R1

FLUID

"Hy-Tran" (five gallon can) (see note A)

1шт.
