Запчасти Case IH 300 (366) - ATTACHMENTS, BELT PULLEY, SPECIAL Attachments

364701R91

1шт.

BELT PULLEY UNIT ATTACHMENT (For tractors equipped with transmission driven power take-off - See Note S) (When it is desired to mount this belt pulley unit on a power take-off w/o provision for mounting the belt pulley, order separately and install housing, 364706R11 and gasket, 66374D) (Column A)

1шт.

364702R91

1шт.

BELT PULLEY UNIT ATTACHMENT (For tractors equipped with independent power take-off - See Note S) (When it is desired to mount this belt pulley unit on a power take-off w/o provision for mounting the belt pulley, order separately and install the following parts (Column B)

1шт.

364713R1

AXLE PIN

BOLT

3шт.

364708R2

COVER

1шт.

359054R2

GASKET

1шт.

360154R1

GASKET

1шт.

364712R12

SHIELD

1шт.

1

364734R11

RETAINER, pulley drive gear bearing, w/ring, 252556R1

1шт.

103878

PLUG

pipe, sq-hd., stl., 1/4"

1шт.

NLS

NO LONGER SERVICED

5шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

5шт.

2

252556R1

O-RING,0.139" Thk x 5.234" ID, -252, Cl 5, 75 Duro

RING, seal, bearing retainer or cage

2шт.

3

358236R1

RING

snap, pulley drive gear bearing

1шт.

4

ST382

BEARING, BALL

w/snap ring

1шт.

5

364730R11

CAGE, pulley drive gear bearing w/ring, 252556R1

1шт.

6

364733R1

SHIM, pulley drive gear bearing cage, heavy (.030")

1шт.

6

364732R1

SHIM, pulley drive gear bearing cage, medium (.012")

1шт.

6

364731R1

SHIM, pulley drive gear bearing cage, light (.007")

1шт.

7

145201R1

PLUG

cup

1шт.

8

364726R11

GEAR, bevel, pulley drive (8-1/16" long shaft) (28 teeth) w/hub, plug, 145201R1 and six rivets, 14276R1 [A]

1шт.

8

364727R91

GEAR, bevel pulley drive (10-1/4" long shaft) (28 teeth) w/hub, plug, 145201R1 and six rivets, 14276R1 [B]

1шт.

14276R1

RIVET, rd-hd., stl., 1/4 x 1-5/16"

6шт.

9

60836H

BREATHER

housing

1шт.

10

364723R21

HOUSING, pulley drive, assembly, Composed of

1шт.

364725R2

BUSHING

1шт.

364723R2

HOUSING (NSS)

1шт.

365416R91

OIL SEAL

OIL SEAL

1шт.

103878

PLUG

1шт.

103881

PLUG

1шт.

103878

PLUG

pipe, sq-hd., stl., 1/4" (Drain plug)

1шт.

103881

PLUG, pipe, sq-hd., stl., 3/4" (Filler plug)

1шт.

179884

BOLT,Hex, 1/2" - 13 x 1 3/8", Gr 5, Full Thd

SCREW, cap, hex-hd., 1/2-13NC x 1-3/8"

4шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

4шт.

11

364725R2

BUSHING, pulley drive gear hub

1шт.

12

365416R91

OIL SEAL

OIL SEAL, pulley drive gear hub (Will work for 364724R91)

1шт.

13

364736R1

GEAR, pulley shaft (16 teeth)

1шт.

70120D

SLOTTED NUT,7/8"-14

NUT, pulley shaft gear retainer

1шт.

103386

COTTER PIN,1/8" x 1 1/4"

Pin, Split (Cotter), 1/8" x 1 1/4"

1шт.

358235R1

WASHER, pulley shaft gear retainer

1шт.

14

ST220

BALL BEARING,39.83mm ID x 110mm OD x 27mm W

BEARING, ball

1шт.

15

364744R1

SPACER, pulley shaft bearing

1шт.

16

364739R1

RING

seal, pulley shaft bearing cage on retainer

2шт.

17

364743R1

SHIM, pulley shaft bearing cage, heavy (.030")

1шт.

17

364742R1

SHIM, pulley shaft bearing cage, medium (.012")

1шт.

17

364741R1

SHIM, pulley shaft bearing cage, light (.007")

1шт.

18

364740R11

CAGE, pulley shaft bearing w/ring, 364739R1

1шт.

19

ST294

BALL BEARING,45 mm ID x 100 mm OD x 25 mm

BEARING, ball, w/snap ring

1шт.

20

364737R11

RETAINER, pulley shaft bearing w/oil seal, 365434R91 and ring, 364739R1

1шт.

179843

BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5

4шт.

103321

LOCK WASHER,3/8"

WASHER, LOCK, 3/8"

4шт.

21

365434R91

OIL SEAL

pulley shaft bearing retainer (Will work for 364738R91)

1шт.

22

40093D

WOODRUFF KEY,#127, 1/4" x 2 1/8", HT

KEY, Woodruff, alloy-stl., no. 127

1шт.

23

364735R1

SHAFT, pulley

1шт.

24

364748R91

PULLEY, belt (11" dia. x 7-1/2" face)

1шт.

181429

BOLT,Hex, 1/2" - 20 x 1 1/4", Gr 5

SCREW, cap, hex-hd., 1/2-20NF x 1-1/4"

6шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

6шт.
