Запчасти Case IH 240 (102) - ELECTRICAL SYSTEM, COMBINATION REAR LIGHT AND TAIL LIGHT, SPECIAL (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH 240 - (102) - ELECTRICAL SYSTEM, COMBINATION REAR LIGHT AND TAIL LIGHT, SPECIAL (06) - ELECTRICAL SYSTEMS
6
14
11
3
2
10
4
15
18
9
5
1
8
7
17
16
12
13

Артикул

Название

Примечание

Количество

1

361985R93

LAMP

LIGHT, combination rear light and tail light, (6 volt) assembly (order 373305R91)

1шт.

2

359773R91

KNOB, switch

1шт.

3

355425R1

NUT, retaining, switch

1шт.

4

359682R91

SWITCH

light, w/knob, 359773R91 and nut, 355425R1 and two screws (less cables), Includes: Ref. 5

1шт.

5

NSS

NOT SOLD SEPARAT

BODY, rear light (not serviced separately) (order 361985R93)

1шт.

6

356590R91

REFLECTOR, rear light, w/socket

1шт.

7

B50206

LAMP

rear (no. 1133) (6 volt)

1шт.

8

53527D

GASKET

rear light

1шт.

9

350478R1

LENS

rear light

1шт.

10

53525DA

MOLDING

MOULDING, rear light

1шт.

11

53526D

SCREW

rear light door

1шт.

12

356592R91

JEWEL, assembly

1шт.

13

115273

LAMP, tail light (no. 51) (6 volt)

1шт.

14

79408H

SPRING, retaining, terminal

1шт.

15

79407H

PLATE

terminal

1шт.

174-211

SCREW,Sl Rnd Hd, #8 - 32 x 5/16"

slotted-rd-hd., cd-pltd., no. 8-32NC x 5/16"

2шт.

138530

LOCK WASHER,Int Tooth, #8

WASHER, LOCK, Int Tooth, #8

2шт.

16

356591R91

SOCKET, w/cable (switch to red light)

1шт.

17

354304R91

CABLE, socket to switch, w/spring

1шт.

18

354303R91

CABLE, switch to terminal plate

1шт.

68417D

INSULATOR

PACKAGE, terminal plate, assembly (consists of (1) plate 79407H, (2) screw 121749, (1) spring 79408H, (2) washer 138530)

1шт.

Выбрано товаров: 21
