Запчасти Case IH 240 (371) - ATTACHMENTS, COTTON PICKER MOUNTING PARTS, SPECIAL, SPARK ARRESTER AND EXHAUST PIPE Attachments

359776R91

ARRESTER, spark, assembly (orchard type) (Farmall 200 and 230) (Composed of, (1) baffle 359779R1, (1) body 359777R11, (2) nut 93082H, (1) plug 103869, (1) top 359778R1)

1шт.

1

359782R1

BRACKET, lower exhaust pipe clamp (Farmall 200 and 230)

1шт.

179841

BOLT,Hex, 3/8" - 16 x 1 1/4", Gr 5

cap, hex-hd, 3/8-16NC x 1-1/4", to be used in the upper left bolt hole of the fan bracket and water outlet when the exhaust pipe clamp bracket is applied

1шт.

2

359780R11

PIPE, exhaust, w/asbestos tape and wire (Farmall 200 and 230)

1шт.

3

359781R1

CLAMP, exhaust pipe (lower) (Farmall 200 and 230)

1шт.

114502

JAM NUT,Jam, 5/16"-18, G5

2шт.

103320

LOCK WASHER,5/16"

WASHER, LOCK, 5/16"

2шт.

4

357758R1

CLAMP, exhaust pipe (upper) (Farmall 200 and 230)

1шт.

102637

NUT,1/2"-13, G5

1шт.

179884

BOLT,Hex, 1/2" - 13 x 1 3/8", Gr 5, Full Thd

SCREW, cap, hex-hd, 1/2NC x 1-3/8"

1шт.

103323

LOCK WASHER,1/2"

WASHER, LOCK, 1/2"

1шт.

5

359778R1

TOP, spark arrester (Farmall 200 and 230)

1шт.

93082H

NUT

"seez-pruf" 3/8-24NF

3шт.

181384

BOLT,Hex, 3/8" - 24 x 2 3/4"

SCREW, cap, hex-hd., 3/8-24NF x 2-3/4"

2шт.

114-259

BOLT,Hex, 3/8" - 24 x 3-1/4", Gr 5

SCREW, cap, hex-hd., 3/8-24NF x 3-1/2"

1шт.

6

359779R1

BAFFLE, spark arrester (Farmall 200 and 230)

1шт.

7

359777R11

BODY, spark arrester, w/plug, 103869, (Farmall 200 and 230)

1шт.

93082H

NUT

"seez-pruf", 3/8-24NF

1шт.

217-442

PLUG,3/4" - 14

pipe, std., sq-hd., 3/4"

1шт.

181385

BOLT,Hex, 3/8" - 24 x 3", Gr 5

SCREW, cap, hex-hd., 3/8-24NF x 3"

1шт.

8

357753R1

FLANGE, spark arrester adapter (Farmall 200)

1шт.

8

367119R1

FLANGE, spark arrester adapter (Farmall 230)

1шт.

360221R11

BEARING

crankshaft, rear (2 halves) (standard) (Farmall 200)

1шт.

360216R11

CRANKSHAFT BEARING

BEARING, crankshaft, center (2 halves) (standard) (Farmall 200)

2шт.

658605R91

BEARING, pillow block, front frame axle support, assembly (optional with 658964R91)

2шт.

658964R91

BEARING, pillow block, front frame axle support, assembly (optional with 658605R91)

2шт.

357778R1

BOWL

fuel strainer (metal)

1шт.

656830R92

COVER, exhaust pipe opering, w/two rivets 135232 (Farmall 200 and 230)

1шт.

9092D

COVER

power take-off

1шт.

186292

BOLT,Hex, 7/16" - 14 x 4 1/4", Gr 5

SCREW, cap, hex-hd, 7/16NC x 4-1/4"

4шт.

103322

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

4шт.

357750R11

CRANK, starting, w/bushing, 355337R1 and pin, 15204D

1шт.

360679R1

GASKET

bowl, fuel strainer

1шт.

60581D

GASKET

power take-off cover

1шт.

657731R1

PIPE, basket hydraulic valve rod

1шт.

432465

PLUG, dust, electrical instrument mounting panel, 17/32" (fuse housing hole)

1шт.

432491

PLUG, dust, electrical instrument mounting panel, 2-3/32" (lighting switch hole)

1шт.

48152D

SPACER

power take-off shaft

1шт.
