(1.77.0[07]) - CONNECTOR, CABLE TERMINAL

Запчасти Case IH JX90U (1.77.0[07]) - CONNECTOR, CABLE TERMINAL (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH JX90U - (1.77.0[07]) - CONNECTOR, CABLE TERMINAL (06) - ELECTRICAL SYSTEMS
10
8
12
5174880
pole
5179221
11
5184015
5179219
5185655
red
82002274
9
red
82862751
7
5185744
5174890
18
16
color
6
pole
5174891
color
12
17
1
5174897
blue
2
15
white
19
color
5177362
5174893
13
5174954
5174955
5
5174892
pole
4
red
3
12
20
5177363
5179220
5174882
24
14
5174896
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82862751

WIRE CONNECTOR,Female

1шт.

2

5174897

MULTIPOLE CONNECTOR,Female, 2 Pole

1шт.

3

5174896

MULTIPOLE CONNECTOR,Female, 2 Pole

1шт.

4

5179219

WIRE CONNECTOR,Male

1шт.

5

5179220

ELEC CONNECTOR,Male

1шт.

6

5179221

ELEC CONNECTOR,Male

1шт.

7

82002274

MULTIPOLE CONNECTOR,Female, 6 Pole

1шт.

8

5174890

MULTIPOLE CONNECTOR,Female, 6 Pole

1шт.

9

5174891

MULTIPOLE CONNECTOR,Female, 6 Pole

1шт.

10

5174880

MULTIPOLE CONNECTOR,Male, 8 Pole

1шт.

11

5177363

MULTIPOLE CONNECTOR,Female, 8 Pole

1шт.

12

5174892

MULTIPOLE CONNECTOR,Female, 3 Pole

1шт.

13

5174882

MULTIPOLE CONNECTOR,Female, 8 Pole

1шт.

14

5177362

ELEC CONNECTOR,Male, 8 Pole

1шт.

15

5174893

MULTIPOLE CONNECTOR,Male, 3 Pole

1шт.

16

5174955

MULTIPOLE CONNECTOR,Female, 4 Pole

1шт.

17

5174954

MULTIPOLE CONNECTOR,Male, 4 Pole

1шт.

18

5184015

MULTIPOLE CONNECTOR,Male, 12 Pole

1шт.

19

5185744

MULTIPOLE CONNECTOR

1шт.

20

5185655

MULTIPOLE CONNECTOR,Female, 24 Pole

1шт.
