(1.40.11/07[01]) - (VAR.406) FRONT AXLE, 40KM/H HYDR. DIFF. LOCK - DIFFERENTIAL GEARS AND SHAFT

Запчасти Case IH JX1090U (1.40.11/07[01]) - (VAR.406) FRONT AXLE, 40KM/H HYDR. DIFF. LOCK - DIFFERENTIAL GEARS AND SHAFT (04) - FRONT AXLE & STEERING

Схема запчастей Case IH JX1090U - (1.40.11/07[01]) - (VAR.406) FRONT AXLE, 40KM/H HYDR. DIFF. LOCK - DIFFERENTIAL GEARS AND SHAFT (04) - FRONT AXLE & STEERING
4
4
2
8
2
4
3
4
6
1
5
3
6
2
7
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

5166550

ARTICULATED SHAFT

RH

1шт.

2

5191547

U-JOINT SPIDER

4шт.

3

5191550

YOKE

2шт.

4

5191548

CIRCLIP

16шт.

5

5166562

ARTICULATED SHAFT

LH

1шт.

6

5191549

SHAFT

199.5 mm

2шт.

7

5191560

SHAFT

1шт.

8

5191559

SHAFT

612.5 mm

1шт.
