Запчасти Case IH JX1080U (1.94.0/04) - (VAR.861) FIXED SAFETY BAR AND RELEVANT PARTS (10) - OPERATORS PLATFORM/CAB

1

5167741

ROPS

1шт.

2

5179685

BOLT

M18X250

4шт.

3

15985221

BOLT,Hex, M18 x 1.5 x 100mm, Cl 8.8

4шт.

4

5179637

RUBBER RING

4шт.

5

5179683

SPACER,19mm ID x 25mm OD x 50mm L

4шт.

6

5179638

RUBBER RING

4шт.

7

5179684

WASHER,18.5mm ID x 57mm OD x 5mm Thk

4шт.

8

12575021

NUT,M18 x 1.5, Cl 10

4шт.

9

5179706

SPACER,25mm OD x 13mm L

18 X25X13

4шт.

10

5179707

PLATE,5mm Thk

2шт.

11

5179708

PLATE,8mm Thk

2шт.

12

5167745

PLATE,20mm Thk

2шт.
