Запчасти Case IH JX1095N (1.87.0/06[02]) - (VAR.101) NOISE REDUCTION PACKAGE - MUDGUARDS AND FOOTBOARDS - L/CAB (08) - SHEET METAL

1

5187531

RUBBER WASHER,16.5mm ID x 60mm OD x 20mm Thk

4шт.

2

5168605

WASHER,Plane, 12.5mm ID x 65mm OD x 3.5mm Thk

12.5x65x3.5

2шт.

2

5177736

WASHER,Plane, 12.5mm ID x 65mm OD x 8mm Thk

12,5x65x8

2шт.

3

16105021

LOCK NUT,M12 x 1.25, Cl 10

2шт.

4

15541424

SCREW,Hex, M12 x 1.25 x 80mm, Cl 8.8

2шт.

5

11190774

BELLEVILLE WASHER,M12 Bolt Size x 24mm OD x 2.8mm Thk

4шт.

6

5178328

SPACER

2шт.

7

5187806

PLATE

LH

1шт.

7

5187807

PLATE

RH

1шт.

8

15540831

BOLT,Hex, M12 x 1.25 x 50mm, Cl 10.9

2шт.

9

11198673

LOCK WASHER,13mm ID x 24mm OD x 0.6mm Thk

M12

2шт.
