Запчасти Case IH JX1095N (1.87.0[01]) - MUDGUARDS AND FOOTBOARDS - L/CAB (08) - SHEET METAL

1

5188433

BRACKET

2шт.

2

5187531

RUBBER WASHER,16.5mm ID x 60mm OD x 20mm Thk

4шт.

3

5168605

WASHER,Plane, 12.5mm ID x 65mm OD x 3.5mm Thk

4шт.

4

5188792

PLUG

DIA=12

2шт.

5

11198673

LOCK WASHER,13mm ID x 24mm OD x 0.6mm Thk

M12

2шт.

6

12164911

NUT,M12 x 1.75, Cl 8

2шт.

7

11198771

BELLEVILLE WASHER,M12 Bolt Size x 30mm OD x 3.4mm Thk

2шт.

8

15008134

BOLT,Hex, M12 x 70mm, Cl 10.9

2шт.

9

11191774

BELLEVILLE WASHER,M20 Bolt Size x 38mm OD x 4.6mm Thk

20x30

4шт.

9

11191674

BELLEVILLE WASHER,M18 Bolt Size x 36mm OD x 4.2mm Thk

4шт.

10

5168604

SPACER,12.25mm ID x 17mm OD x 40mm L

2шт.

11

11124530

BOLT,Hex, M20 x 45, 10.9, Full Thd

4шт.

11

15984624

SCREW,Hex, M18 x 1.5 x 70mm, Cl 8.8

, Serial Range: -HJC032231

4шт.

11

11408524

BOLT,Hex, M18 x 1.5 x 40mm, Cl 8.8

, Start Serial: HJC032232

4шт.

12

5188719

PLUG

DIA=49.5

2шт.

13

5190114

SPACER

, Serial Range: -HJC032231

4шт.
