Запчасти Case IH JX1095N (1.43.0/03[02]) - (VAR495) 4WD WIDENED FRONT FENDERS (04) - FRONT AXLE & STEERING

1

47137895

HUB

2шт.

2

47137897

BRACKET

RH

1шт.

2

47137896

SUPPORT

LH

1шт.

3

47137898

ROLLER BEARING,20mm ID x 15mm W

20x42x15

2шт.

4

47137899

NUT,Hex, M20 x 1

M10

2шт.

5

47137900

O-RING,2.62mm Thk x 47mm ID

2шт.

6

47137914

SPRING

RH

1шт.

6

47137901

SPRING

LH

1шт.

7

47132631

DOWEL,M14 x 1.5mm

M14x1.5

2шт.

8

11191074

BELLEVILLE WASHER,M14 Bolt Size x 27mm OD x 2.6mm Thk

2шт.

9

10791324

THIN NUT,Thin, M14 x 1.5, Cl 05

2шт.

10

47137902

COVER

2шт.

11

47137904

SUPPORT

RH

1шт.

11

47137903

BRACKET

LH

1шт.

12

47137905

SCREW

M12x45

2шт.

13

16101524

NUT,M12 x 1.25, Cl 10

2шт.

14

11198574

BELLEVILLE WASHER,Belleville, M10.5

2шт.

15

15970724

SCREW,Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd

2шт.

16

15970724

SCREW,Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd

2шт.

17

47137907

SCREW,M16 x 1.5

M16x1.5

2шт.

18

11194274

BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 3.4mm Thk

2шт.

19

12575921

NUT,M16 x 1.5, Cl 05

2шт.

20

14496621

WASHER,10.5mm ID x 21mm OD x 2mm Thk

6шт.

21

16204524

BOLT,Hex, M10 x 1.25 x 35mm, Cl 8.8

6шт.

22

47137908

SPACER

6шт.

23

47137909

O-RING

DIA=108

6шт.
