(1.98.0/02) - (VAR.324-324/1) STANDARD FRONT AXLE W/LOCK, DIFFERENTIAL MECHANIK (40KM/H) - PLATES

Запчасти Case IH JX1095C (1.98.0/02) - (VAR.324-324/1) STANDARD FRONT AXLE W/LOCK, DIFFERENTIAL MECHANIK (40KM/H) - PLATES (13) - DECALS

Схема запчастей Case IH JX1095C - (1.98.0/02) - (VAR.324-324/1) STANDARD FRONT AXLE W/LOCK, DIFFERENTIAL MECHANIK (40KM/H) - PLATES (13) - DECALS
2
8
7
4
1
3
5
6
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

5179879

DECAL

Speed, 28 Creeper, 40 KM/H

1шт.

2

5184758

DECAL

Speed, 16 Mech., 40 KM/H

1шт.

3

5184760

DECAL

Speed, 16 Mech., 40 KM/H

1шт.

4

5184761

DECAL

Speed, 16 Mech., 40 KM/H

1шт.

5

5184858

DECAL

Speed, 28 Creeper, 40 KM/H

1шт.

6

5184859

DECAL

Speed, 28 Creeper, 40 KM/H

1шт.

7

5184860

DECAL

Speed, 28 Creeper, 40 KM/H

1шт.

8

5184861

DECAL

Speed, 28 Creeper, 40 KM/H

1шт.
