(1.75.4/13[02]) - (VAR.031) FRONT HPL W/PTO & BRAKES W/ELECT. CONTROL - AUXILIARY CABLES

Запчасти Case IH JX1095C (1.75.4/13[02]) - (VAR.031) FRONT HPL W/PTO & BRAKES W/ELECT. CONTROL - AUXILIARY CABLES (06) - ELECTRICAL SYSTEMS

Схема запчастей Case IH JX1095C - (1.75.4/13[02]) - (VAR.031) FRONT HPL W/PTO & BRAKES W/ELECT. CONTROL - AUXILIARY CABLES (06) - ELECTRICAL SYSTEMS
3
1
2
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87313743

ELECTRIC CABLE

1шт.

EFH, Cab

1шт.

2

87353575

ELECTRIC CABLE

1шт.

EFH, Transmission

1шт.

3

87306772

BRACKET

1шт.
