Запчасти Case IH JX95 (1.21.1[02]) - SUPPORT - COVER, SCREWS AND CAPS (03) - TRANSMISSION

Схема запчастей Case IH JX95 - (1.21.1[02]) - SUPPORT - COVER, SCREWS AND CAPS (03) - TRANSMISSION
9
6
1.40.0/1
5
12
3
9
8
1
10
16
7
13
14
15
8
11
4
10
2

Артикул

Название

Примечание

Количество

1

5098047

AXLE SUPPORT

, Serial Range: -C6936

1шт.

1

84362946

AXLE SUPPORT

, Start Serial: D6936

1шт.

2

4668595

DOWEL,18mm OD x 22mm L

2шт.

3

5125208

BOLT,Hex, M18 x 1.5 x 75mm

4шт.

4

590353

PLUG,15mm OD x 10mm High, Plastic

8шт.

5

5111887

SUPPORT

JX60, JX70

1шт.

5

5140454

SUPPORT

JX80, JX90, JX95

1шт.

6

5111877

SUPPORT

JX60, JX70

1шт.

6

5140453

SUPPORT

JX80, JX90, JX95

1шт.

7

5129385

BUSHING,99.15mm ID x 103.7mm OD x 52mm L

1шт.

8

10837710

DOWEL,M10 x 25

2шт.

9

13407211

LUBE NIPPLE,M10 x 1

JX60, JX70

1шт.

9

13407214

LUBE NIPPLE,M10 x 1

JX80, JX90, JX95

1шт.

10

14272034

LOCK BOLT,Hex, M18 x 1.5 x 65mm, Cl 10.9

4шт.

11

5111886

SUPPORT

JX60, JX70

1шт.

11

5140452

SUPPORT

JX80, JX90, JX95

1шт.

12

5101112

BUSHING,52.72mm ID x 57.16mm OD x 42mm L

1шт.

13

5111874

SUPPORT

JX60, JX70

1шт.

13

5140451

SUPPORT

JX80, JX90, JX95

1шт.

14

5140455

SEALING RING,99mm ID x 115mm OD x 7,5mm Thk

JX80, JX90, JX95

2шт.

15

14471380

O-RING,0.21" Thk x 2.1" ID, -330, Cl 5, 75 Duro

JX80, JX90, JX95

1шт.

16

13411117

VALVE PRESSURE RELIE,M10, Black

JX80, JX90, JX95

1шт.

Выбрано товаров: 22
