(81.00) - 2WD FRONT WHEELS

Запчасти Case IH JX80 (81.00) - 2WD FRONT WHEELS (11) - WHEELS/TRACKS

Схема запчастей Case IH JX80 - (81.00) - 2WD FRONT WHEELS (11) - WHEELS/TRACKS
rim
4
w8x16
7.50-20 6ply r1
81.11
6.00-16 8ply r1
81.26/1
81.25
9.00-16 8ply r1
81.18
7.50-16 8ply r1
81.11/2
81.09
5.50f-20
5.50f-20
7.50-20 8ply r1
7.50-18 8ply r1
3
5.50f-16
5.50f-16
81.26
5.50f-18
10.00-16 8ply f2
equip.
81.14
1
81.11/1
7.50-16 a6
5.50f-16
2
7.50-16 6ply f2
tire size
4.00e-16
1.58.3
w8x16
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

5090035

RIM

W8 x 16

2шт.

1

5091731

RIM

5.50F-16D, JX60, JX70, JX80

2шт.

1

5091734

RIM

5.50F-18, JX80, JX90, JX95

2шт.

1

5090037

WHEEL

5.50F-20, JX90, JX95

2шт.

1

5092352

WHEEL

4.00E-16, JX60, JX70

2шт.

1

5128677

RIM,W5.5 x 16, 6 Bolts, NH White

5.50Fx16, JX60, JX70, JX80

2шт.

2

15983821

SCREW,Hex, M18 x 1.5 x 35mm, Cl 8.8, Full Thd

12шт.

3

10572279

WASHER,M18

12шт.

4

87323751

PNEUMATIC VALVE

2шт.

Выбрано товаров: 9
