Запчасти Case IH JX80 (1.87.4/01[01]) - (VAR.860) 2WD FRONT MUDGUARDS - 240 MM. (08) - SHEET METAL

1

5125199

REAR FENDER

RH

1шт.

2

5125190

REAR FENDER

LH

1шт.

3

5125270

COVER ASSY

2шт.

4

5125197

REAR FENDER

RH

1шт.

5

5125188

REAR FENDER

LH

1шт.

6

5122259

REINFORCEMENT

4шт.

7

5122260

COVER PLATE

1шт.

8

13181301

CARRIAGE BOLT,Sq Nk, M8 x 1.25 x 45mm, Cl 4.6

12шт.

9

10519601

WASHER,8.15mm ID x 17mm OD x 2mm Thk

12шт.

10

12605579

WASHER

12шт.

11

16102311

THIN NUT,Thin, M8 x 1.25, Cl 04

12шт.

12

10571879

LOCK WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk

4шт.

13

15970721

SCREW,Hex, M10 x 1.25 x 25mm, Cl 8.8, Full Thd

4шт.

14

5125186

SPACER

17 x 32 x 8

2шт.

15

15977921

SCREW,Hex, M14 x 1.5 x 90mm, Cl 8.8

2шт.
